Step 2: Configure the Management IP
Address Settings
1 In IP Version Support, select one of the following options:
• IPv4 Only: Click this option if you want the controller to obtain an IPv4
address from a DHCP server on the network.
• IPv4 and IPv6: Click this option if you want the controller to obtain both IPv4
and IPv6 addresses from DHCP and DHCPv6 servers on the network.
2 Configure the IP address settings of the Control (AP/DataPlane) interface.
a Under the IPv4 section, click Static, and then enter the network settings that
you want to assign to the AP/DataPlane interface, through which client traffic
and configuration data are sent and received.
NOTE: Although it is possible to use DHCP to assign IP address settings to the
Control interface automatically, Ruckus Wireless strongly recommends assigning a
static IP address to this interface.
WARNING!
subnets. Failure to do so may result in loss of access to the web interface or failure
of system functions and services.
The following network settings are required (others are optional):
- IP address
- Netmask
- Default gateway
b If you clicked IPv4 and IPv6 at the beginning of this procedure, under the
IPv6 section, click Auto Configuration if you want the controller to obtain its
IP address from Router Advertisements (RAs) or from a DHCPv6 server on
the network. If you want to manually assign the IPv6 network address, click
Static, and then set the values for the following:
- IP address (IPv6): Enter an IPv6 address (global only) with a prefix length
(for example, 1234::5678:0:C12/123). Link-local addresses are
unsupported.
- Gateway: Enter an IPv6 address (global or link-local) without a prefix
length. Here are examples:
•
•
SmartCell Gateway 200 Getting Started Guide for SmartZone 3.5.1, 800-71517-001 Rev A
You must configure the three interfaces to be on three different
Global address without a prefix length: 1234::5678:0:C12
Link-local address without a prefix length: fe80::5678:0:C12
Running the Setup Wizard and Logging On to the Web Interface

Step 2: Configure the Management IP Address Settings
