Ruckus Wireless SmartCell Gateway 200 Getting Started Manual page 42

c Click the Cluster tab when done.
Figure 21. The Cluster tab
3 On the Cluster tab, click Static under the IPv4 section, and then enter the
network settings that you want to assign to the cluster interface, through which
cluster data will be sent and received.
NOTE: Although it is possible to use DHCP to assign IP address settings to the
Cluster interface automatically, Ruckus Wireless strongly recommends assigning a
static IP address to this interface.
WARNING!
subnets. Failure to do so may result in loss of access to the web interface or failure
of system functions and services.
The following network settings are required (others are optional):
• IP address
• Netmask
• Default gateway
Click the Management (Web) tab when done.
SmartCell Gateway 200 Getting Started Guide for SmartZone 3.5.1, 800-71517-001 Rev A
You must configure the three SCG interfaces to be on three different
Running the Setup Wizard and Logging On to the Web Interface
Step 2: Configure the Management IP Address Settings
42
