DC PSU LED
Table 9 describes the behavior of the DC PSU LED.
Table 9. DC PSU LED behavior
LED State
Off
Amber
Blinking Amber
Blinking Green
Green
SmartCell Gateway 200 Getting Started Guide for SmartZone 3.5.1, 800-71517-001 Rev A
Description
No DC to all power supplies
• No DC to this PSU only (for 1+1 configuration), or;
• Power supply critical event causing a shutdown: failure, fuse
blown (1+1 only), OCP (12V), OVP (12V), fan failed
Power supply warning events where power supply continues to
operate: high temp, high power/high current, slow fan
DC present / Only 5Vsb on (PS off)
Output ON and OK
Mounting and Powering the SCG
Powering On the SCG
