Alarm Volume - GE Medical Systems Dash 2000 Operator's Manual

Alarm Volume

4-10
To adjust the volume of the alarm tones, follow this procedure:
1. Select ALARM VOL option from the Alarm Control Menu.
2. A popup menu opens displaying all choices.
MAIN
MENU
PREV.
MENU
ALARM VOL Popup Menu
3. Rotate the Trim Knob control to change the selection. Each time the
control is rotated, you hear a tone at that volume. ALARM VOL. OFF
message is displayed at the top of the screen if OFF is selected.
NOTE: When in Neonatal-ICU mode, alarm volume cannot be turned off.
The lowest it can be set is 10%.
4. When you are satisfied with the volume level, press the Trim Knob
control to close the popup menu.
Any change made with this menu option is only temporary and will revert
to default upon discharge.
Dash 2000 Patient Monitor
2005873-001
ALARM
100 % 40 %
VOL:
90 % 30 %
OFF
80 % 20 %
70 % 10 %
60 %
OFF
50 %
049
Revision C
