Size

Auto Size

Manual Size

Revision C
The size of the waveform can be changed manually or automatically. To
perform this operation, follow this procedure:
1. Select SIZE option from the Respiration Menu; a new set of menu
options is displayed.
MAIN
MENU
PREV.
MENU
2. Select either AUTOSIZE or MANUAL SIZE option.
NOTE: The size of the waveform has no effect on the detection capability
of the program.
During the learning process, the displayed waveform is automatically sized to
fit a predetermined area of the screen. During monitoring, the size may have
been changed manually (see below). Select AUTO SIZE option to
automatically resize the waveform to fit the predetermined area. This is a
direct action menu option.
If desired, you can manually change the size of the respiration waveform.
1. Select MANUAL SIZE option from the Respiration Size Menu. A popup
menu opens displaying the choices available.
MAIN
MENU
PREV.
MENU
MANUAL SIZE Popup Menu
2. Rotate the Trim Knob control to highlight another size. The change will
occur immediately.
3. When you are satisfied with the size, press the Trim Knob control to
close the popup menu.
NOTE: The manual size you select will be cancelled if you change the lead
from which respiration is derived. When you change leads, the
learning process is started and the waveform is automatically
sized.
Dash 2000 Patient Monitor
2005873-001
MANUAL
AUTO

SIZE:

SIZE
4X
Respiration Size Menu
MANUAL
10X
SIZE:
9X
4X
8X
7X
6X
129
5X
4X
3X
2X
1X
129A
12-11
