ECG Limits

Heart Rate

8-14
This option provides an information window that shows the heart rate alarm
limits. A limits menu is displayed to allow you to adjust these limits.
Follow these procedures:
1. Select ECG LIMITS from the ECG Menu. An information window is
displayed on the screen and a related set of menu options is displayed
in the menu area.
21-NOV-2000 16:27
II

ECG LIMITS

>
RETURN
HR
MAIN
MENU
ECG LIMITS Menu and Information Window
1. Rotate the Trim Knob control to move the pointer (>) through the list.
2. Press the Trim Knob control when the pointer is in front of HR. The
parameter label highlights.
3. Turn the Trim Knob control to highlight the low or high limit.
4. Press the Trim Knob control again and rotate to change value. Press
the Trim Knob control to complete the change.
5. Rotate the Trim Knob control to highlight the parameter label and
press to unhighlight.
6. Select RETURN when all changes are completed. The popup menu and
information window close.
Dash 2000 Patient Monitor
2005873-001
DAK.BED 1
UNITS LOW HIGH
BPM 50 150
ECG
LIMITS
089
Revision C
