GE Medical Systems LOGIQ 7 Reference Manual

Hide thumbs Also See for LOGIQ 7:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Quick Manual
GE Medical Systems
Technical
Publications
Direction 5116269-100
Rev. 2
LOGIQ 7/LOGIQ 7 Pro Advanced Reference
Manual
R4.2.0/R4.2.0Pro
Copyright© 2004, 2005 By General Electric Co.
Operating Documentation

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LOGIQ 7 and is the answer not in the manual?

Questions and answers

Related Manuals for GE Medical Systems LOGIQ 7

Summary of Contents for GE Medical Systems LOGIQ 7

  • Page 1 GE Medical Systems Technical Publications Direction 5116269-100 Rev. 2 LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual R4.2.0/R4.2.0Pro Copyright© 2004, 2005 By General Electric Co. Operating Documentation...
  • Page 2 This product complies with regulatory requirements of the following European Directive 93/42/EEC concerning medical devices This manual is a reference for the LOGIQ 7/LOGIQ 7 Pro. It applies to all versions of the SW R4.2.0/R4.2.0Pro and later software for the LOGIQ 7/LOGIQ 7 Pro ultrasound systems.
  • Page 3 GE Sales Representative or in the USA call the GE Ultrasound Clinical Answer Center at 1 800 682 5327 or 1 262 524 5698. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 4 This page intentionally left blank. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...

  • Page 5: Table Of Contents

    Mercer - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-54 LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual...
  • Page 6 Yarkoni - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-88 LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual...

  • Page 7: Chapter 1 - Acoustic Output

    Chapter 1 Acoustic Output Provides Acoustic Output information and tables, as well as possible bioeffects and prudent use. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...

  • Page 8: Bioeffects

    To contact the AIUM concerning their publications: • In the USA, by telephone at 1-800-638-5352. • To write them, use the following address: AIUM 14750 Sweitzer Lane Suite 100 Laurel, MD, USA 20707-5906 LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...

  • Page 9: Acoustic Output Data

    Maximum output summary The following tables list the typical maimum acoustic output levels achievalbe with LOGIQ 7/LOGIQ 7 Pro for all probes and operational modes. It is intended that this is information be useful in making ALARA decisions and selecting the most appropriate probe for the application.
  • Page 10 M12L i12L T739 M3S* B-mode <1 M-mode <1 <1 (inc.B-mode) Color Flow (inc. B- mode) Pulsed Doppler <1 (inc.B-mode) B-Flow Contrast CW Doppler <1 Other (specify) *LOGIQ 7 Only LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 11 Distance from the Source to a Specified Point / (same) Depth for TIB / Depth at which the relevant index is maximum Break-Point Depth / (same) Depth for TIS / Depth at whcih the relevant index is maximum LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 12 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 13 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 14 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 15 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 16 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 17 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 18 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 19 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 20 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 21 I @PII (cm) Focal Length (cm) (cm) at max. MI 173.6 (W/cm pa,α PA.3 Frequency (MHz) BF3.3 D2.0 T4.0 Image Depth (cm) 25.0 Vel Scale (kHz) 1.23 Penet LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 22 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 23 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 24 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 25 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 26 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 27 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 28 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 29 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 30 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 31 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 32 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 33 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 34 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 35 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 36 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 37 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 38 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 39 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 40 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 41 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 42 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 43 Acoustic Output Data M7C Probe (LOGIQ 7 Only) (continued) (LOGIQ 7 Only) Table 1-2: Transducer Mode: M7C Operating Mode: M-Mode (inc.B-mode) Index Label non-scan scan non- Aaprt< Aaprt>1 scan Global Maximum: Index Value <1 <1 Units (MPa) (mW) 20.3 75.9...
  • Page 44 Acoustic Output M7C Probe (LOGIQ 7 Only) (continued) (LOGIQ 7 Only) Table 1-3: Transducer Mode: M7C Operating Mode: CF-Mode (inch.M-mode) Index Label non-scan scan non- Aaprt< Aaprt>1 scan Global Maximum: Index Value <1 Units (MPa) (mW) 78.9 54.2 78.9 min of [P...
  • Page 45 Acoustic Output Data M7C Probe (LOGIQ 7 Only) (continued) (LOGIQ 7 Only) Table 1-4: Transducer Mode: M7C Operating Mode: PWD-Mode (inch.B-mode) Index Label non-scan scan non- Aaprt< Aaprt>1 scan Global Maximum: Index Value <1 <1 Units (MPa) (mW) 78.9 54.2...
  • Page 46 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 47 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 48 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 49 I @PII (cm) Focal Length (cm) (cm) at max. MI 902.5 (W/cm pa,α PA.3 Frequency (MHz) BF4.0 BF4.0 D4.0 Image Depth (cm) 14.0 Vel Scale (kHz) 1.60 Penet LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 50 (Hz) 4721.4 at max. I @PII (MPa) at max. I @PII (cm) Focal Length (cm) (cm) at max. MI 486.6 (W/cm pa,α PA.3 Frequency (MHz) Image Depth (cm) 14.0 LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 51 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 52 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 53 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 54 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 55 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 56 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 57 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 58 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 59 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 60 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 61 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 62 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 63 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 64 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 65 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 66 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 67 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 68 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 69 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 70 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 71 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 72 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 73 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 74 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 75 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 76 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 77 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 78 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 79 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 80 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 81 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 82 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 83 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 84 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 85 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 86 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 87 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 88 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 89 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 90 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 91 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 92 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 93 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 94 Acoustic Output M3S Probe (LOGIQ 7 Only) (continued) (LOGIQ 7 Only) Table 1-53: Transducer Mode: M3S Operating Mode: M-Mode (inc.B-mode) Index Label non-scan scan non- Aaprt< Aaprt>1 scan Global Maximum: Index Value <1 <1 <1 <1 Units (MPa) (mW) min of [P...
  • Page 95 Acoustic Output Data M3S Probe (LOGIQ 7 Only) (continued) (LOGIQ 7 Only) Table 1-54: Transducer Mode: M3S Operating Mode: CF-Mode (inch.M-mode) Index Label non-scan scan non- Aaprt< Aaprt>1 scan Global Maximum: Index Value <1 <1 Units (MPa) (mW) 86.0 94.7...
  • Page 96 Acoustic Output M3S Probe (LOGIQ 7 Only) (continued) (LOGIQ 7 Only) Table 1-55: Transducer Mode: M3S Operating Mode: PWD-Mode (inch.B-mode) Index Label non-scan scan non- Aaprt< Aaprt>1 scan Global Maximum: Index Value <1 <1 Units (MPa) (mW) 94.7 94.7 min of [P...
  • Page 97 Acoustic Output Data M3S Probe (LOGIQ 7 Only) (continued) (LOGIQ 7 Only) Table 1-56: Transducer Mode: M3S Operating Mode: Contrast Index Label non-scan scan non- Aaprt< Aaprt>1 scan Global Maximum: Index Value <1 Units (MPa) (mW) 90.5 min of [P...
  • Page 98 Acoustic Output M3S Probe (LOGIQ 7 Only) (continued) (LOGIQ 7 Only) Table 1-57: Transducer Mode: M3SOperating Mode: CWD-Mode Index Label non-scan scan non- Aaprt< Aaprt>1 scan Global Maximum: Index Value <1 <1 <1 Units (MPa) (mW) 86.0 min of [P...
  • Page 99 This formulation for TIS is less than that for an alternate formulation in this mode. # No data are reported for this operating condition since the global maximum index value is not reported for the reason listed. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 100 Acoustic Output LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...

  • Page 101: Chapter 2 - Measurement Formulas

    Chapter 2 Measurement Formulas Reference for measurement formula tables for the various applications. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...

  • Page 102: Cardiac Measurement

    PISA:Regurgitant Orifice Area AR Flow PISA:Regurgitant Flow ml/s AR PHT AV Insuf. Pressure Half Time AP Rad PISA:Radius of Aliased Point AR RV PISA:Regurgitant Volume Flow AR Vel PISA:Aliased Velocity LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 103 CO (MOD A2C) CO 2CH, Single Plane, MOD (Simpson) l/min CO (MOD A4C) CO 4CH, Single Plane, 4CH, MOD (Simpson) l/min CO (Cube) Cardiac Output, 2D, Cubic l/min LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 104 Left Ventricle Volume, Systolic, 2D, Cubic ESV (Cube) Left Ventircle Volume, Systolic, M-mode, Cubic ESV (Teich) Left Ventricle Volume, Systolic, 2D, Teicholtz ESV (Teich) Left Ventricle Volume, Systolic, M-mode, Teicholtz LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 105 LA Diameter to AoRoot Diameter Ratio, 2D LA/Ao LA Diameter to AoRoot Diameter Ratio, M-mode LAEDV (MOD LA Volume, Single Plane, MOD A4C) LAESV (MOD LA Volume, Systolic, SIngle Plane MOD A4C) LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 106 LVESV (MOD BP) LV Volume, Systolic, Bi-Plane, MOD LVESV (MOD LV Volume, Diastolic, Apical View, LAX MOD LAX) LV ESV (MOD LV Volume, Systolic, Apical View, LAX, MOD LAX) LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 107 LV Mass Index, Systolic, M-mode LAAd (A2C) Left Atrium Area, Apical 2C LAAd (A4C) Left Atrium Area, Apical 4C Mitral Valve Closure to Opening MP Area Mitral Valve Prosthesis LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 108 Mitral Valve Pressure Half Time MV SI Stroke Volume Index by Mitral Flow ml/m MV SV Stroke Volume by Mitral Flow MV Time to Peak Mitral Valve Time to Peak LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 109 PV an Diam Pulmonic Valve Annulus Diameter, 2D PV Ann Area Pulmonic Valve Area PV CO Cardiac Output by Pulmonic Flow l/min PV max PG Pulmonic Valve Peak Pressure Gradient mmHg LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 110 Regurgitant Jet Area ratio RJA/LAA RV Major Right Ventricle Major RV Minor Right Ventricle Minor RVAWd Right Ventricle Wall Thickness, Diastolic, 2D RVAWs Right Ventricle Wall Thickness, Systolic, 2D LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 111 LV Stroke Index, Single Plane, 4CH, MOD ml/m SI (Teich) LV Stroke Index, Teicholtz, 2D ml/m SI (Teich) LV Stroke Index, Teicholtz, M-mode ml/m SV (A-LA2C) LV Stroke Volume, Single Plane, 2CH, Area-Length LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 112 TV Valve E Velocity TV E/A Ratio Tricuspid Valve E-Peak to A-Peak Ratio TV max PG Tricuspid Valve Peak Pressure Gradient mmHg TV mean PG Tricuspid Valve Mean Pressure Gradient mmHg LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 113 Stroke Volume by Tricuspid Flow TV Vmean TV Mean Velocity TV VTI Tricuspid Valve Velocity Time Integral VSD max PG VSD Peak Pressure Gradient mmHg VSD Vmax VSD Peak Velocity LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 114 TAMEAN=sum{V } from t1 (Trace method is Mean) Doppler display to t2/(t2-t1) [cm/s or m/s] a.Vdiastole = Vmin or Vend-diastole (depends on preset selection) LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 115 Urology Volume x PPSA- Coefficient2 NOTE: PPSA is Predicted PSA. NOTE: PSA is Prostatic Specific Antigen concentration. NOTE: You must type manually PSA/PPSA-Coefficient1/PPSA- Coefficient2 in the Patient menu screen. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...

  • Page 116: Formulas-Abdominal/Small Parts

    Table 2-5: Abdominal/Small Parts Calculation Formulas Calc Name Input Measurements Formula Thyroid Volume three distance Vol[ml]=0.479xLxWxH Testicle Volume three distance Vol[ml]= 0.523598775xLxWxH Renal Volume three distance Vol[ml]=0.49xLxWxH π Vol[ml]= ( /6)xLxWxH LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...

  • Page 117: Formulas-Ob

    Diagnosis in Obstetrics and Gynecology, 438-9, 1985 Ejection two distances on M- EF = (1 - Ds^3 / Dd^3) Fraction Mode (End-diastolic dimension and End- systolic dimension on M-Mode) LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 118 BPD, AC, and FL EFW [g]=10^(1.335- Hadlock, Weight (0.0034*AC [cm] * FL [cm]) + AJOG, (0.0316 * BPD [cm]) + 151:333, 1985 (0.0457 * AC [cm]) + (0.1623 * FL [cm] LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 119 University TTD [cm] * FL [cm] Estimated Fetal BPD, AxT, FL [cm] EFW1 [g] =1.07 * BPD Tokyo Weight [cm]^3 + 3.42 * AxT [cm2] * Shinozuka FL [cm] LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 120 70, No. 3, Part 1, p.353-6, Sept. 1987. 28-40 weeks 15.0 cm = average >20.0 - 24.0 = hydramnios Transverse <5.0-6.0 = Oligohydramnios Dr. C.C. Smith, The Female Patient, Volume 15, p.85-97, March 1990. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...

  • Page 121: Formulas-Gyn

    Left Ovary Follicles One distance D1[cm] π Two distances D1[cm] x D2x[cm] : (D1 <D2) π D1[cm] x D2[cm] : (D2 <D1) π Three distances D1[cm] x D2[cm]x D3[cm] x LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 122 V (depends on preset selection) diastole end-diastole b.To calculate LtOvFo or RtOvFo with one (or two distances), press the Clear key after the first (or second distance) measurement(s). LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...

  • Page 123: Formulas-Vascular

    Heart Rate (beats/minute) one 2 beat time interval HR[BPM]=120[sec]/ (measured manually or 2 beat time[sec] automatically) Vol. Flow Volume Flow dTamean*dDiam*dDiam*0.785 dTamax*dDiam*dDiam*0.785 or V (depends on preset selection) diastole end-diastole LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...

  • Page 124: Formulas-Cardiac

    Measured by: Ao st junct [2DCALIPER] Ao/LA [Generic, Dimension] Mode: MM:CM:AMM:CAMM:VRMM Formula: {Ao Diam}/{LA Diam} Needs measurement: Ao Diam [Generic, Dimension], LA Diam [Generic, Dimension] Measured by: LA/Ao [MMLAAO] LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 125 Needs measurement: AV Diam [Aortic], AV VTI [Aortic] Measured by: AV Trace [SDMANTRACE] AV SV [Aortic] Mode: CW:PW:VRCW:VRPW Formula: {AV Diam}^2*0.785*{AV VTI} Needs measurement: AV Diam [Aortic], AV VTI [Aortic] Measured by: AV Trace [SDMANTRACE] LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 126 Formula: (({LVEDV A-L A4C}-{LVESV A-L A4C})*{HR}/60)/{BSA} Needs measurement: LVEDV A-L A4C [Single Plane A4C], LVESV A-L A4C [Single Plane A4C], HR [Single Plane A4C] Measured by: LVESV A4C [2DVOLUMETRACE] LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 127 Formula: (({LVEDV MOD A4C}-{LVESV MOD A4C})*{HR}/60)/{BSA} Needs measurement: LVEDV MOD A4C [Single Plane A4C], LVESV MOD A4C [Single Plane A4C], HR [Single Plane A4C] Measured by: LVESV A4C [2DVOLUMETRACE] LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 128 Formula: ({LVEDV A-L A2C}-{LVESV A-L A2C})*{HR}/60 Needs measurement: LVEDV A-L A2C [Single Plane A2C, AutoBiplane], LVESV A-L A2C [Single Plane A2C, AutoBiplane], HR [Single Plane A2C, AutoBiplane] Measured by: R-R [2DCALIPER], A2C [2DAUTOVOLUME] LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 129 Mode: 2D:CF:VR2D:Trace Formula: (d-s)*{ECG/HeartRate}/60 where: s =5/6*{LVAs(sax)}*{LVLs(apical)} d = 5/6*{LVAd sax)}*{LVLd apical} Needs measurement: LVAd sax) [Bullet], LVLd apical [Bullet], LVLs apical [Bullet], HR [Bullet] Measured by: R-R [2DCALIPER] LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 130 PM[Modified Simpson], LVLs apical [Modified Simpson], LVAs sax MV [Modified Simpson], LVAs sax PM[Modified Simpson], HR [Modified Simpson] Measured by: R-R [2DCALIPER] CO(A-L) [Generic] Mode: 2D:CF:Trace Formula: ({EDV(A-L)}-{ESV(A-L)})*{HR}/60 Needs measurement: ESV(A-L) [Generic], HR [Generic] Measured by: R-R [2DCALIPER] LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 131 Needs measurement: LVLd apical [Modified Simpson], LVAd (sax MV) [Modified Simpson], LVAd sax PM[Modified Simpson] Measured by: EF mod sim [AUTOCALC] EDV(Cube) [Dimension, Cube/Teicholz] Mode: 2D:CF:VR2D Formula: {LVIDd}^3 Needs measurement: LVIDd [Dimension, Cube/Teicholz] Measured by: LVd [2DLV], LVIDd [2DCALIPER], EF(Cube) [AUTOCALC] LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 132 Needs measurement: LVLd apical [Modified Simpson], LVAd (sax MV) [Modified Simpson], LVAd sax PM [Modified Simpson], LVLs apical [Modified Simpson], LVAs sax MV [Modified Simpson], LVAs sax PM [Modified Simpson] Measured by: EF mod sim [AUTOCALC] LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 133 Formula: ({LVLs apical}/9)*((4*{LVAs sax MV})+(2*{LVAs sax PM})+sqrt({LVAs sax MV}*{LVAs sax PM})) Needs measurement: LVLs apical [Modified Simpson], LVAs sax MV [Modified Simpson], LVAs sax PM [Modified Simpson] Measured by: EF mod sim [AUTOCALC] LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 134 HR [Generic] Mode: CW:PW:VRCW:VRPW Formula: 60/{Time} Needs measurement: Time [Generic] Measured by: Heartrate [SDTIMECALIPER] IVSd/LVPWd [Dimension] Mode: MM:CM:AMM:CAMM:VRMM Formula: {IVSd}/{LVPWd} Needs measurement: IVSd [Dimension], LVPWd [Dimension] Measured by: LVPWd [MMDISCALIPER] LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 135 Formula: m/{BSA} where: m = 1.05*5/6*({LVAd(sax epi)}*({LVLd(apical)}+t)-{LVAd(sax PM)}*{LVLd(apical)})/ 1000 t = sqrt({LVAd sax EPI}/3.14159)-sqrt({LVAd sax PM}/3.14159) Needs measurement: LVAd sax EPI [Mass], LVAd sax PM [Mass], LVLd apical [Mass] Measured by: LVMass(d) [AUTOCALC] LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 136 Needs measurement: LVEDV MOD A4C [Biplane, Single Plane A4C, AutoBiplane], LVESV MOD A4C [Biplane, Single Plane A4C, AutoBiplane] Measured by: EF SP A4C [AUTOCALC], LVESV A4C [2DVOLUMETRACE], A4C [2DAUTOVOLUME] LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 137 Used to calculate: AP Area LVOT Diam [Mitral Valve] Mode: CW:PW:VRCW:VRPW Formula: {LVOT Diam} Needs measurement: LVOT Diam [Mitral Valve] Measured by: MP Area [SDMANTRACE] Used to calculate: MP Area LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 138 Needs measurement: LVAs sax EPI [Mass], LVAs sax PM [Mass], LVLs apical [Mass] Measured by: LVMass(s) [AUTOCALC] LVs Mass Ind (ASE) [Generic] Mode: MM:CM:AMM:CAMM:VRMM Formula: (((1.04*(({IVSs}+{LVIDs}+{LVPWs})^3-({LVIDs})^3))*0.8+0.6)/1000)/{BSA} Needs measurement: IVSs [Generic], LVIDs [Generic], LVPWs [Generic] Measured by: LV Study [MMLV] LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 139 Measured by: MR Trace [AUTOCALC] MV AccT/DecT [Mitral Valve] Mode: CW:PW:VRCW:VRPW Formula: {MV AccT}/{MV DecT} Needs measurement: MV AccT [Mitral Valve], MV DecT [Mitral Valve] Measured by: MV AccT [SDCALIPER] LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 140 P Vein S/D Ratio [Pulmonary Vein] Mode: PW:VRPW Formula: {P Vein S}/{P Vein D} Needs measurement: P Vein S [Pulmonary Vein], P Vein D [Pulmonary Vein] Measured by: P Vein D [SDPTCALIPER] LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 141 Mode: PW:VRPW Formula: {P Vein A Dur}-{MV A Dur} Needs measurement: P Vein A Dur [Pulmonary Vein], MV A Dur [Pulmonary Vein] Measured by: P Vein A Dur [SDTIMECALIPER] LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 142 Formula: 3.14159/4*{Pulmonic Diam}^2*{Pulmonic VTI}/(3.14159/4*{Systemic Diam}^2*{Systemic VTI}) Needs measurement: Pulmonic Diam [Shunts, Congenital Heart], Pulmonic VTI [Shunts, Congenital Heart], Systemic Diam [Shunts, Congenital Heart], Systemic VTI [Shunts, Congenital Heart] Measured by: Qp/Qs [AUTOCALC] LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 143 Needs measurement: RVPEP [Time], RVET [Time] Measured by: RVET [MMTIMECALIPER] RVSP [Tricuspid Valve] Mode: CW:PW:VRCW:VRPW Formula: {TR maxPG}+{RAP} Needs measurement: TR maxPG [Tricuspid Valve], RAP [Tricuspid Valve] Measured by: TR Vmax [AUTOCALC] LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 144 Needs measurement: LVEDV MOD A4C [Biplane, Single Plane A4C, AutoBiplane], LVESV MOD A4C [Biplane, Single Plane A4C, AutoBiplane] Measured by: EF SP A4C [AUTOCALC], LVESV A4C [2DVOLUMETRACE], A4C [2DAUTOVOLUME] LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 145 Measured by: LVs [2DLV], LVIDs [2DCALIPER], EF(Cube) [AUTOCALC] SI(Teich) [Generic] Mode: MM:CM:AMM:CAMM:VRMM Formula: (dv-sv)/{BSA} where: sv = 7/(2.4+{MM/LVIDs})*{MM/LVIDs}^3 dv = 7/(2.4+{LVIDd})*{LVIDd}^3 Needs measurement: LVIDd [Generic], LVIDd [Generic], LVIDs [Generic] Measured by: LV Study [MMLV] LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 146 Needs measurement: LVEDV MOD A4C [Biplane, Single Plane A4C, AutoBiplane], LVESV MOD A4C [Biplane, Single Plane A4C, AutoBiplane] Measured by: EF SP A4C [AUTOCALC], LVESV A4C [2DVOLUMETRACE], A4C [2DAUTOVOLUME] LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 147 Measured by: LV Study [MMLV], LVIDs [MMDISCALIPER] Systemic CO [Shunts, Congenital Heart] Mode: CW:PW:VRCW:VRPW Formula: {Systemic SV}*{Systemic HR}/60 Needs measurement: Systemic SV [Shunts, Congenital Heart], Systemic HR [Shunts, Congenital Heart] Measured by: Systemic VTI [SDMANTRACE] LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 148 Measured by: TV A Vel [SDPTCALIPER] TV SI [Tricuspid Valve] Mode: CW:PW:VRCW:VRPW Formula: ({TV Ann Diam}^2*0.785*{TV VTI})/{BSA} Needs measurement: TV Ann Diam [Tricuspid Valve], TV VTI [Tricuspid Valve] Measured by: TV Trace [SDMANTRACE] LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 149 Needs measurement: LVIDd [Dimension], LVIDs [Dimension], LVET [Dimension] Measured by: Vcf [MMTIMECALIPER] Vcf mn (corr) [Dimension] Mode: MM:CM:AMM:CAMM:VRMM Formula: ({LVIDd}-{LVIDs})/({LVIDd}*({LVET}/sqrt({Time}))) Needs measurement: LVIDd [Dimension], LVIDs [Dimension], LVET [Dimension], Time [Dimension] Measured by: Vcf [MMTIMECALIPER] LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 150 Measurement Formulas LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...

  • Page 151: Chapter 3 - Ob Tables

    Chapter 3 OB Tables Reference for Obstetric Measurement Tables. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...

  • Page 152: Ob Tables

    —— Table 3-2: BPD: ASUM, Aust NZ, Obstet Gynaecol 1989: 29:26 (Fetal Age) Unit: BPD (mm); Age (Days); 2SD (Days - * signifies No Data) <20 —— >98 —— LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 153 Table Type=SD, Table Range=2SD, Graph Range=2SD Meas Mean Meas Mean Meas Mean Table 3-5: ASUM2000/AC Table/Fetal Growth Unit: AG(week); mean(mm); SD (Day) Table Type=SD, Table Range=2SD, Graph Range=2SD Meas Mean Meas Mean Meas Mean LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 154 Meas Mean Meas Mean Meas Mean Table 3-8: ASUM2000/FL Table/Fetal Age Unit: meas (mm); mean(week); SD (day) Table Type=SD, Table Range=2SD, Graph Range=2SD Meas Mean Meas Mean Meas Mean LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 155 Table Type=SD, Table Range=2SD, Graph Range=2SD Meas Mean Meas Mean Meas Mean Table 3-11: ASUM2000/HC Table/Fetal Growth Unit: AGE(week); mean(mm); SD (day) Table Type=SD, Table Range=2SD, Graph Range=2SD Meas Mean Meas Mean Meas Mean LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 156 Meas Mean Meas Mean Meas Mean Table 3-14: ASUM2000/OFD Table/Fetal Age Unit: meas (mm); mean(week); SD (day) Table Type=SD, Table Range=2SD, Graph Range=2SD Meas Mean Meas Mean Meas Mean LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 157 10+5 13+2 10+6 13+3 11+0 13+4 11+1 13+5 11+2 13+6 11+3 14+0 11+4 14+1 11+5 14+2 11+6 14+3 12+0 14+4 12+1 12+2 12+3 10+0 12+4 10+1 12+5 10+2 12+6 LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...

  • Page 158: Berkowitz

    12+0 14+4 12+1 12+2 12+3 10+0 12+4 10+1 12+5 10+2 12+6 Berkowitz Table 3-18: BD: Berkowitz (Fetal Age) Unit: BD (mm); Age (Day); SD (mm) <13 —— >59 —— LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...

  • Page 159: Bertagnoli

    1890 41.0 2800 3360 3980 30.0 1030 1460 2100 42.0 2830 3410 4060 31.0 1180 1630 2290 43.0 2840 3420 4100 32.0 1310 1810 2500 44.0 2790 3390 4110 LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...

  • Page 160: Campbell

    23.91 31.74 7.09 16.34 24.94 32.64 8.27 17.46 25.96 33.53 9.45 18.56 26.96 34.40 10.62 19.66 27.95 35.25 11.78 20.74 28.92 36.08 12.93 21.81 29.88 36.89 14.08 22.87 30.82 LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 161 23w2d 8.80 30w4d 33w6d 37w4d 5.40 19w6d 21w5d 23w5d 8.90 30w6d 34w2d 38w1d 5.50 20w1d 22w0d 24w0d 9.00 31w1d 34w5d 38w4d 5.60 20w3d 22w2d 24w3d 9.10 31w4d 35w1d 39w0d LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 162 22w5d 6.40 30w4d 33w4d 36w6d 3.60 19w5d 20w5d 23w1d 6.50 31w0d 34w1d 37w3d 3.70 20w1d 21w0d 23w4d 6.60 31w3d 34w4d 38w0d 3.80 20w3d 21w3d 24w0d 6.70 32w0d 35w1d 38w5d LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 163 9.48 11.72 2.97 6.66 9.96 11.67 3.58 6.88 10.16 11.74 3.86 7.32 10.55 11.80 4.39 7.90 10.86 12.07 4.72 8.22 10.98 12.41 5.29 8.68 11.09 12.06 5.81 9.08 11.24 LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 164 30.17 33.53 16.49 18.56 20.63 30.95 34.40 37.85 17.50 19.66 21.81 31.72 35.52 38.78 18.50 20.74 22.98 32.46 36.08 39.70 33.18 36.89 40.60 19.48 21.81 24.14 20.45 22.87 25.28 LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 165 11.74 13.29 6.63 7.32 8.01 11.04 11.80 12.56 7.36 7.90 8.44 10.62 12.07 13.52 7.68 8.22 8.76 11.24 12.41 13.58 11.02 12.06 13.10 7.94 8.68 9.42 8.45 9.08 9.71 LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...

  • Page 166: Eriksen

    OB Tables Eriksen Table 3-30: TAD: Eriksen (Fetal Age) Unit: TAD (mm); Age (Day); SD (mm) <23 —— >112 —— LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...

  • Page 167: Erik-Nes

    16+6 22+3 28+3 37+3 17+1 22+5 28+5 37+7 17+3 23+0 29+1 38+5 17+5 23+2 29+4 39+3 17+7 23+4 29+6 38+7 18+2 23+7 30+2 18+5 24+2 30+5 19+0 24+4 31+1 LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 168 37+5 20+6 26+3 31+5 38+1 21+1 26+5 31+7 38+4 21+3 26+7 32+2 39+0 21+5 27+2 32+4 39+4 22+0 27+4 32+6 40+1 22+3 27+5 33+1 40+5 22+5 28+0 33+3 41+2 LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...

  • Page 169: Goldstein

    OB Tables Goldstein Table 3-35: TCD: Goldstein et a, Am J OB/GYN, May 1987 (Fetal Growth) Unit: TCD (Weeks); Age/Quat1/Mean/Quat3/Max (mm) Quat1 Mean Quat3 21.5 28.5 40.5 48.5 LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...

  • Page 170: Hadlock

    34.5 2.96 18.5 2.06 26.4 2.18 34.9 2.96 Table 3-37: AC: Hadlock, AJR; 139: 367-370; 1982 (Fetal Age) Unit: AC (mm); Age (Days); SD (Days) <47 —— >353 —— LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 171 1.19 23.4 1.73 32.1 3.08 42.6 3.20 16.8 1.19 23.8 1.73 32.5 3.08 >103 —— a.Variability of GA estimate by BPD at term is ± 2 SD (6 weeks) LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 172 Table 3-39: BPD: Hadlock, J Ultrasound Med 1:97-104, April 1982 (Fetal Age) Unit: BPD (mm); Age (Days ); SD (Days) <20 —— >100 —— Table 3-40: CI: Hadlock, AJR, 137: 83, 1981 (Fetal Growth) Min (Index) Max (Index) LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 173 Unit: EFW (grams); Mean (Weeks); SD (grams) Mean Mean Mean <35 —— 2162 2377 2595 2813 3028 3236 1055 3435 3619 1210 1379 3787 1559 >3787 —— 1751 1953 LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 174 1.38 24.5 2.08 33.1 2.96 >83 —— Table 3-44: FL: Hadlock, AJR 138: 875-878, May 1982 (Fetal Age) Unit: FL (mm); Age (Days); 2SD (Days) <10 —— —— >79 LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 175 16.6 1.19 23.1 1.48 31.3 2.98 >360 —— Table 3-46: HC: Hadlock, AJR 138: 649-653, 1982 (Fetal Age) Unit: HC (mm); Age (Days); 2SD (Days) <69 —— >354 —— LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 176 19.3 21.3 21.6 23.2 18.4 20.2 19.1 21.3 20.1 23.9 19.2 20.8 19.9 21.5 >42 Table 3-48: FL/AC Ratio: Hadlock (Fetal Growth) Unit: Age (Weeks) Min (Index) Max (Index) LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...

  • Page 177: Hansmann

    29w4d 14w6d 19w4d 24w6d 29w5d 14w6d 19w5d 25w0d 29w6d 15w0d 19w6d 25w1d 30w0d 15w0d 20w0d 25w2d 30w1d 15w1d 20w1d 25w2d 30w2d 15w2d 20w2d 25w3d 30w3d 15w2d 20w2d 25w4d 30w3d LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 178 36w1d 38w2d 32w0d 34w1d 36w2d 38w4d 32w1d 34w2d 36w2d 38w5d 32w2d 34w2d 36w3d 39w0d 32w2d 34w3d 36w3d 39w1d 32w3d 34w3d 36w4d >320 —— 32w3d 34w4d 36w4d 32w4d 34w4d 36w5d LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 179 39w3d 20w5d 39w3d 20w6d 40w3d 21w0d 39w4d 21w1d 41w3d 21w3d 39w5d 21w2d >101 —— 21w5d 39w6d 21w4d 22w0d 40w0d 21w6d 22w2d 40w1d 22w2d 22w5d 40w2d 22w4d 23w0d >105 —— LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 180 14w4d 18w3d 22w2d 11w3d 14w5d 18w4d 22w3d 11w4d 14w6d 18w4d 22w3d 11w4d 14w6d 18w5d 22w4d 11w5d 15w0d 18w6d >175 —— 11w5d 15w0d 19w0d 11w6d 15w1d 19w1d 11w6d 15w2d 19w1d LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 181 28w4d 36w5d 16w2d 22w1d 29w0d 37w2d 16w4d 22w4d 29w3d 37w6d 16w6d 22w6d 29w6d 38w3d 17w2d 23w2d 30w2d 39w0d 17w4d 23w5d 30w5d >75 —— 17w6d 24w0d 31w2d 18w2d 24w3d 31w5d LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 182 32w5d 15w5d 21w0d 26w2d 33w3d 16w1d 21w2d 26w5d 34w2d 16w4d 21w5d 27w1d 35w1d 17w0d 22w1d 27w4d 36w2d 17w3d 22w4d 28w1d 37w6d 17w6d 23w0d 28w5d >345 —— 18w1d 23w3d 29w1d LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 183 >115 —— Table 3-56: TAD: Hansmann (Fetal Age) Hansmann: M and Al: Geburtsh, u, Frauenheilk 39: 656, 1979 Unit: TAD (mm); Age (Days); SD (mm) <20 —— >103 —— LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 184 12+0 20+0 28+0 36+0 13+0 21+0 29+0 37+0 14+0 22+0 30+0 38+0 15+0 23+0 31+0 39+0 16+0 24+0 32+0 40+0 17+0 25+0 33+0 18+0 26+0 34+0 19+0 27+0 35+0 LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...

  • Page 185: Hellman

    31.8 ± 1.2 38.3 ± 1.6 22.8 ± 0.9 32.3 ± 1.2 38.5 ± 1.6 23.5 ± 0.9 32.8 ± 1.2 >56 —— 24.2 ± 1.01 33.4 ± 1.2 LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...

  • Page 186: Hohler

    Unit: AC (mm); Age (Day); SD (mm) <50 —— >315 —— Table 3-63: BD: Jeanty (Fetal Age) Jeanty: Radiology 143: 513, 1982 Unit: BD (mm); Age (Days); SD (mm) <15 —— >65 —— LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 187 38w6d 16w6d 19w4d 22w2d 34w0d 36w5d 39w3d 17w1d 19w6d 22w4d 34w4d 37w1d 39w6d 17w4d 20w2d 22w6d 35w0d 37w5d 40w3d 17w6d 20w4d 23w1d 35w4d 38w2d 40w6d 18w1d 20w6d 23w4d >95 LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 188 22.0+0 38.0+0 23.0+0 39.0+0 24.0+0 40.0+0 25.0+0 Table 3-66: CRL: Jeanty (Fetal Age) Jeanty: Radiology 143: 513, 1982 Unit: CRL (mm); Age (Days); SD (mm) <5 —— >54 —— LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 189 OB Tables Table 3-67: FIB: Jeanty (Fetal Growth) Fetal Limb Bimetry (Letter), Radiology 147:602, 1983 Unit: Age (Weeks); Min/Mean/Max (mm); Table/Graph Range: 5%:95% Mean Mean LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 190 26w1d 36w3d 38w4d 40w6d 22w1d 24w2d 26w4d 36w6d 39w1d 41w2d 22w4d 24w5d 26w6d 37w2d 39w4d 41w5d 22w6d 25w0d 27w1d 37w6d 40w0d 42w1d 23w1d 25w3d 27w4d >80 23w4d 25w6d 28w0d LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 191 12.0+0 27.0+0 13.0+0 28.0+0 14.0+0 29.0+0 15.0+0 30.0+0 31.0+0 16.0+0 17.0+0 32.0+0 18.0+0 33.0+0 19.0+0 34.0+0 35.0+0 20.0+0 21.0+0 36.0+0 22.0+0 37.0+0 23.0+0 38.0+0 24.0+0 39.0+0 25.0+0 40.0+0 26.0+0 LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 192 23w4d 37w2d 39w2d 41w2d 20w1d 22w0d 23w7d 38w1d 40w0d 42w0d 20w4d 22w3d 24w3d 38w6d 40w6d 42w6d 20w7d 22w7d 24w6d 39w5d 41w5d 43w4d 21w3d 23w3d 25w3d >360 21w6d 23w6d 25w6d LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 193 12.0+0 27.0+0 13.0+0 28.0+0 14.0+0 29.0+0 15.0+0 30.0+0 31.0+0 16.0+0 17.0+0 32.0+0 18.0+0 33.0+0 19.0+0 34.0+0 35.0+0 20.0+0 21.0+0 36.0+0 22.0+0 37.0+0 23.0+0 38.0+0 24.0+0 39.0+0 25.0+0 40.0+0 26.0+0 LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 194 40w4d 19w2d 22w0d 24w6d 35w4d 38w2d 41w1d 19w5d 22w4d 25w1d 36w1d 38w6d 41w5d 20w1d 22w6d 25w5d 36w6d 39w4d 42w2d 20w4d 23w3d 26w1d 37w3d 40w1d 42w6d 21w1d 23w6d 26w4d >69 LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 195 OB Tables Table 3-73: Radius: Jeanty (Fetal Growth) Fetal Limb Bimetry (Letter), Radiology 147:602, 1983 Unit: Age (weeks); Min/Mean/Max (mm); Table/Graph Range: 5%:95% Mean Mean <11 >40 LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 196 40w3d 20w1d 23w1d 26w0d 35w1d 38w0d 41w0d 20w4d 23w4d 26w3d 35w5d 38w4d 41w4d 21w0d 23w6d 26w6d 36w1d 39w1d 42w0d 21w4d 24w3d 27w2d 36w6d 39w5d 42w4d 21w6d 24w6d 27w5d >69 LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 197 41w3d 19w1d 35w2d 38w2d 19w4d 22w5d 25w5d 35w6d 39w0d 42w0d 20w1d 23w1d 26w1d 36w4d 39w4d 42w5d 20w4d 23w4d 26w5d 37w1d 40w2d 43w2d 21w1d 24w1d 27w1d >64 21w4d 24w4d 27w5d LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...

  • Page 198: Jsum

    38+0 3.85 52.6 22+0 2.96 90.6 39+0 3.90 55.7 23+0 3.01 91.5 40+0 3.96 58.8 24+0 3.07 92.2 41+0 4.01 61.7 25+0 3.12 92.6 42+0 4.07 64.6 26+0 3.18 LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 199 289.84 25+0 112.64 2,676 37+0 308.83 26+0 126.35 2,838 38+0 328.30 1,023 27+0 140.53 2,989 39+0 348.25 1,163 28+0 155.20 3,125 40+0 368.68 1,313 29+0 170.35 3,244 41+0 389.59 LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 200 0.793 0.862 0.920 0.929 0.669 0.688 0.793 0.859 0.863 0.775 0.794 0.865 0.922 0.930 0.649 0.666 0.775 0.844 0.849 0.773 0.792 0.865 0.923 0.930 0.627 0.643 0.757 0.827 0.833 LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 201 0.618 0.676 0.730 0.771 0.462 0.538 0.599 0.628 0.688 0.559 0.608 0.666 0.720 0.762 0.456 0.534 0.596 0.620 0.682 0.547 0.598 0.657 0.710 0.754 0.450 0.531 0.593 0.612 0.676 LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...

  • Page 202: Kurtz

    OB Tables Kurtz Table 3-85: BPD: Kurtz (Fetal Age) Journal of Clinical Ultrasound, 8: 319-326, 1980 Unit: BPD (mm); Age (Days); SD (mm) <21 —— >98 —— LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...

  • Page 203: Mayden

    15.0 21.8 28.6 37.8 15.5 22.3 29.1 38.3 22.3 29.6 38.3 15.5 16.0 22.8 30.0 39.3 16.5 23.3 30.6 39.8 16.5 23.3 31.0 17.0 23.8 31.5 17.5 24.3 32.0 LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...

  • Page 204: Mercer

    23.7 35.3 38.4 41.4 20.8 22.7 24.5 36.1 39.2 42.4 21.5 23.4 25.2 36.9 40.1 43.3 26.0 37.7 41.0 22.2 24.1 44.2 22.9 24.9 26.8 >86 23.6 25.6 27.6 LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...

  • Page 205: Merz

    20w2d 21w6d 27w5d 29w4d 31w4d 19w0d 20w4d 22w0d 27w6d 29w6d 31w5d 19w1d 20w5d 22w1d 28w1d 30w0d 31w6d 19w2d 20w6d 22w3d 28w2d 30w1d 32w1d 19w4d 21w1d 22w4d 28w3d 30w3d 32w2d LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 206 36w4d 37w0d 39w2d 41w4d 32w4d 34w4d 36w5d 37w1d 39w4d 41w6d 32w4d 34w5d 36w6d 37w3d 39w5d 42w0d 34w6d 37w1d 32w6d 37w4d 39w6d 42w1d 33w0d 35w1d 37w1d >348 33w1d 35w2d 37w3d LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 207 35.0 20.0 20.5 35.5 21.0 36.0 21.5 36.5 37.0 22.0 22.5 37.5 23.0 38.0 23.5 38.5 39.0 24.0 24.5 39.5 25.0 40.0 25.5 40.5 26.0 41.0 26.5 41.5 27.0 LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 208 40w5d 20w4d 22w4d 24w3d 36w3d 38w6d 41w1d 22w6d 39w2d 20w6d 24w5d 36w6d 41w6d 21w1d 23w1d 25w1d 37w2d 39w6d 42w2d 21w4d 23w4d 25w4d 37w6d 40w2d 42w6d 21w6d 23w6d 25w6d >102 LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 209 35.0 20.0 20.5 35.5 21.0 36.0 21.5 36.5 37.0 22.0 22.5 37.5 23.0 38.0 23.5 38.5 39.0 24.0 24.5 39.5 25.0 40.0 25.5 40.5 26.0 41.0 26.5 41.5 27.0 LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 210 24w6d 36w4d 38w5d 40w6d 21w5d 23w3d 25w1d 37w0d 39w1d 41w3d 22w1d 23w6d 25w4d 37w3d 39w4d 41w6d 22w4d 24w1d 25w6d 37w6d 40w1d 42w2d 22w6d 24w4d 26w3d >80 23w1d 25w0d 26w6d LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 211 35.0 20.0 20.5 35.5 21.0 36.0 21.5 36.5 37.0 22.0 22.5 37.5 23.0 38.0 23.5 38.5 39.0 24.0 24.5 39.5 25.0 40.0 25.5 40.5 26.0 41.0 26.5 41.5 27.0 LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 212 18w4d 20w0d 25w4d 27w3d 29w1d 17w1d 18w5d 20w1d 25w6d 27w4d 29w3d 17w2d 18w6d 20w2d 26w0d 27w6d 29w4d 17w4d 19w0d 20w4d 26w1d 28w1d 30w0d 17w4d 19w1d 20w4d 26w3d 28w2d 30w1d LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 213 34w4d 37w1d 39w4d 41w6d 37w4d 30w6d 32w6d 34w6d 39w6d 42w1d 31w1d 33w1d 35w1d 37w6d 40w1d 42w3d 31w3d 33w3d 35w3d 38w1d 40w4d 42w6d 31w4d 33w4d 35w4d >364 33w6d 36w0d 31w6d LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 214 35.0 20.0 20.5 35.5 21.0 36.0 21.5 36.5 37.0 22.0 22.5 37.5 23.0 38.0 23.5 38.5 39.0 24.0 24.5 39.5 25.0 40.0 25.5 40.5 26.0 41.0 26.5 41.5 27.0 LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...

  • Page 215: Moore

    14.4 26,9 11.6 21.6 14.7 23.8 14.3 27.4 11.0 19.2 Nelson Table 3-98: CRL: Nelson (Fetal Age) Journal of Clinical Ultrasound, 9: 67-70, 1981 Unit: CRL (mm); GA (Days) LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...

  • Page 216: Osaka

    <13 —— >94 —— Table 3-100: CRL: Osaka (Fetal Age) Osaka University Method 1989, 3 by Univ. Osaka Unit: CRL (mm); Age (Days); SD (mm) <9 —— >63 —— LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 217 1220 2160 3100 1240 2180 3120 1260 2200 3140 1280 2220 3160 1300 2240 3180 1320 2260 3200 1340 2280 3220 1360 2300 >3220 —— 1380 2320 1400 2340 LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 218 1900 4100 6300 8500 1010 4200 8600 1040 2000 6400 2100 4300 6500 8660 1040 2200 4400 6600 >8660 —— 2300 4500 6700 2400 4600 6800 2500 4700 6900 LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 219 OB Tables Table 3-104: HL: Osaka (Fetal Age) Osaka University Method 1989, 3 by Univ. Osaka Unit: HL (mm); Age (Days); SD (mm) <10 —— >62 —— LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...

  • Page 220: Paris

    Table 3-105: BPD: Paris (Fetal Age) Unit: BPD (mm); Age (Days); SD (mm) <13 —— >90 —— Table 3-106: CRL: Paris (Fetal Age) Unit: CRL (mm); Age (Days); SD (mm) <5 —— >85 —— LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 221 Table 3-107: FL: Paris (Fetal Age) Unit: FL (mm); Age (Days); SD (mm) <15 —— >77 —— Table 3-108: Ft: Paris (Fetal Age) Unit: Ft (mm); Age (Days); SD (mm) <13 —— >75 —— LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 222 OB Tables Table 3-109: TAD: Paris (Fetal Age) Unit: TAD (mm); Age (Days); SD (mm) <10 —— >96 —— LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...

  • Page 223: Rempen

    21.8 7w6d 10w2d 14.8 12w5d 22.2 8w0d 10w3d 15.2 12w6d 22.6 8w1d 10w4d 15.7 13w0d 23.1 8w2d 10w5d 16.1 13w1d 23.5 8w3d 10w6d 16.5 13w2d 23.9 8w4d 11w0d 17.0 LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 224 9w5d 13w2d 9w5d 9w6d 13w2d 9w6d 9w6d 13w3d 10w0d 10w0d 13w3d 10w1d 10w1d 13w4d 10w1d 10w2d 13w4d 10w2d 10w2d 13w4d 10w3d 10w3d 13w5d 10w4d 10w4d >78 —— 10w4d 10w5d LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 225 13.5 10w1d 34.6 12w5d 60.3 7w5d 14.6 10w2d 35.9 12w6d 61.9 63.5 7w6d 15.6 10w3d 37.2 13w0d 8w0d 16.7 10w4d 38.5 13w1d 65.1 8w1d 17.8 10w5d 39.9 13w2d 66.7 LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 226 7w6d 13w0d 8w0d 8w0d 13w1d 8w0d 8w1d 13w2d 8w1d 8w2d 13w3d 8w2d 8w3d 13w4d 8w3d 8w3d 13w5d 8w4d 8w4d 14w0d 8w5d 8w5d 14w1d 8w6d 8w6d >73 —— 9w0d 9w0d LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 227 43.1 10.5 13w0d 59.1 10.5 7w1d 22.9 10.5 10w1d 44.0 10.5 13w1d 59.7 10.5 44.9 10.5 13w2d 7w2d 24.0 10.5 10w2d 60.3 10.5 7w3d 25.1 10.5 10w3d 45.7 10.5 LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...

  • Page 228: Robinson

    23w4d ± 9d 31w3d ± 14d 39w2d ± 19d 24w1d ± 10d 31w6d ± 14d >90 —— 24w5d ± 10d 32w3d ± 15d 25w2d ± 10d 32w6d ± 15d LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 229 76.0 91.5 107.0 109.7 111.4 40.0 74.3 76.1 78.9 95.1 111.4 114.2 116.0 41.0 76.8 78.6 81.6 98.6 115.7 118.6 120.5 42.0 79.1 81.1 84.1 102.0 119.8 122.9 124.8 LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 230 ± 7 ± 7 ± 7 ± 8 ± 7 ± 7 ± 7 ± 9 ± 7 ± 7 ± 7 ± 7 ± 7 ± 7 >50 —— LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 231 ± 11 ± 10 ± 6 ± 9 ± 11 >86 —— ± 6 ± 10 ± 11 ± 7 ± 10 ± 11 ± 7 ± 10 ± 11 LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...

  • Page 232: Tokyo Shinozuka

    31.1 34.3 17.7 20.1 22.3 28.2 31.8 35.0 18.6 21.0 23.3 28.8 32.4 35.7 19.5 22.0 24.4 29.3 33.0 36.4 20.3 22.9 25.4 29.7 33.6 37.0 21.1 23.8 26.4 LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 233 87.7 106.7 27.9 36.7 45.6 71.6 91.5 111.4 74.3 95.1 116.0 30.9 40.3 49.8 33.9 44.1 54.2 76.8 98.6 120.5 37.1 47.9 58.7 79.1 102.0 124.8 40.3 51.8 63.3 LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 234 90.1 96.5 49.3 54.2 59.1 84.6 91.1 97.5 52.3 57.3 62.3 85.3 91.8 98.4 55.2 60.3 65.3 85.8 92.4 99.0 58.0 63.2 68.4 86.0 92.8 99.5 60.8 66.0 71.3 LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 235 31.8 12w4d 53.9 8w3d 16.1 10w4d 33.1 12w5d 55.5 8w4d 17.1 10w5d 34.4 12w6d 57.2 8w5d 18.1 10w6d 35.8 13w0d 58.9 8w6d 19.1 11w0d 37.1 9w0d 20.1 11w1d 38.5 LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 236 2420 2880 2102 2592 3083 1026 2236 2758 3280 1175 2360 2915 3469 1092 1334 2471 3059 3647 1237 1504 2565 3187 3809 1099 1391 1683 2639 3296 3952 LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 237 68.0 73.6 39.0 43.9 48.7 63.5 69.1 74.7 41.3 46.2 51.1 64.4 70.1 75.8 43.5 48.4 53.4 65.3 71.0 76.7 45.6 50.6 55.7 65.9 71.7 77.5 47.7 52.8 57.9 LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...

  • Page 238: Williams

    38w4d 42w0d 43w6d 19w1d 24w4d 28w0d 35w0d 38w3d 21w0d 24w3d 29w6d 35w6d 39w2d 44w5d 21w5d 25w1d 30w5d 36w5d 40w1d 45w4d 22w4d 26w0d 30w3d 36w3d 41w6d 45w3d 22w3d 27w6d 31w2d LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 239 OB Tables This page intentionally left blank. LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 240 OB Tables LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 241 Renal Volume , 2-16 T739 , 1-62 RI , 2-14 Amniotic Fluid Index (AFI) , 2-20 Rt. Ovarian Volume , 2-21 TAMAX , 2-14 TAMEAN , 2-14 TAMIN , 2-14 LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Index Direction 5116269-100 Rev. 2...
  • Page 242 Calculation Formula , 2-15 PPSA2 Calculation Formula , 2-15 Left Ovary Follicles Prostate Volume Calculation Formula , 2-21 Calculation Formula , 2-15 Lt. Ovarian Volume Calculation Formula , 2-21 Index LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...
  • Page 243 Calculation Formula , 2-16 Thyroid Volume Calculation Formula , 2-16 Urology Calculation Formulas , 2-15, , 2-16 Uterine Volume Calculation Formula , 2-21 Volume Calculation Formulas , 2-15 LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Index Direction 5116269-100 Rev. 2...
  • Page 244 Index LOGIQ 7/LOGIQ 7 Pro Advanced Reference Manual Direction 5116269-100 Rev. 2...

This manual is also suitable for:

Logiq 7 pro

Table of Contents
