Getting to the ECG
Menu
8-10
To display the ECG Menu, use the Trim Knob control to select the ECG
parameter label. Remember, selecting with the Trim Knob control is a two-step
process—rotate to highlight, then press to select.
ECG
60
*
P
Selecting the ECG Parameter Label
The ECG Menu is displayed at the bottom of the screen.
MAIN
MENU
With the Trim Knob control, you can now select any of the displayed options.
•
DISPLAY LEAD—change the top displayed (primary) ECG lead.
•
ECG SIZE—change the size of all ECG waveforms displayed and
graphed.
•
ECG LIMITS—display a new menu and an information window to
adjust heart rate alarm limits.
•
RELEARN—relearn the patient's QRS pattern to enable more accurate
monitoring.
•
QRS VOLUME—turn the QRS tone on/off, and adjust volume when on.
•
ANALYSIS SETTINGS—displays a new menu to adjust single or multi-
lead analysis, pace detection, and filter settings.
Detailed information on each option is found in this chapter.
Dash 2000 Patient Monitor
2005873-001
150/ 50
ECG
DISPLAY
SIZE:
LEAD II
1X
QRS
ANALYSIS
RELEARN VOLUME:
SETTINGS
OFF
ECG Menu
084
ECG
LIMITS
085
Revision C
