Setup Default
Parameter Priority
Revision C
This menu option allows you to select how the parameter windows are
prioritized on the display.
1. Select PARAM PRIORITY option from the Monitor Defaults Menu. A
popup menu and information window open.
21-NOV-2000 16:27
II
DEFAULT PARAMETER PRIORITY
> RETURN
PARAMETER 1
PARAMETER 2
PARAMETER 3
NBP
CVP
ART
RA
FEM
UVC
UAC
LA
PA
ICP
MAIN
PARAM
MENU PRIORITY
PREV.
MENU
PARAM PRIORITY Popup Menu and Information Window
2. Using the rotate and press technique with the Trim Knob control, select
parameters for positions on the display.
The PARAMETER selections in the top half of the window are the ones
displayed as full-size windows on the right side of the screen. You control
the order of these when you designate a parameter for each position.
The parameters in the lower half of the window will be displayed at the
bottom of the screen only when there is no room at the side. You cannot
control the order of parameters displayed across the bottom of the screen.
The system prioritizes these for you.
See the next page for additional information which may be helpful to you
when prioritizing parameters.
Dash 2000 Patient Monitor
2005873-001
DAK.BED 1
ECG
SPO2
All parameters
RESP
which can be
SP
monitored are
SPO2
listed (illustration
RESP
shown includes
TEMP
BP option).
066
5-9
