Setup Default Limits

Revision C
You can set default limits for all parameters also.
1. Select DEFAULT LIMITS from the Monitor Defaults Menu. A popup
menu and information window are displayed.
21-NOV-2000 16:27
II

SETUP DEFAULT LIMITS

>
RETURN
HR
SPO2
RR
RR-APNEA
NBP-S
NBP-D
NBP-M
TP
MAIN
MENU
PREV.
MENU
DEFAULT LIMITS Popup Menu and Information Window
2. Rotate the Trim Knob control to move the pointer (>) through the list.
3. Press the Trim Knob control when the pointer is in front of the
parameter for which you want to change default limits. The parameter
label highlights.
4. Turn the Trim Knob control to highlight the low or high limit.
5. Press the Trim Knob control again and rotate to change the value.
Press the Trim Knob control to complete the change.
6. Rotate the Trim Knob control to highlight the parameter label and
press to unhighlight.
7. Select RETURN when all changes are completed. The popup menu and
information window close.
Dash 2000 Patient Monitor
2005873-001
DAK.BED 1
UNITS
LOW
HIGH
BPM
50
150
%
90
105
#/MIN
5
55
SEC
20
mmHg
80
200
mmHg
20
120
mmHg
40
140
˚C
30.0
42.0
DEFAULT
LIMITS
066A
5-7
