Graph Location

5-18
The GRAPH LOCATION option displays a menu which allows you to
choose writers for alarm and manual graphs. This menu is shown in the
figure below.
MAIN
MENU
PREV.
MENU
GRAPH LOCATION Menu
MANUAL GRAPH LOCATION—designate to which writer a graph
strip with patient waveforms will be printed. A manual graph is
started and stopped with the GRAPH GO / STOP key on the front of the
monitor.
ALARM GRAPH LOCATION—designate to which writer an alarm
graph strip with patient waveforms will be printed. An alarm graph is
automatically started when a Crisis or Warning alarm occurs.
PRINT WINDOW LOCATION—designate to which writer the data
from an information window will be printed.
You can designate a different writer for each type of graph. Described on
the following page is the procedure for selecting a manual graph location.
Use the same procedure when selecting an alarm graph location and print
window location.
NOTE: The Graph Location Menu is also accessible via the Admit Patient
Menu when the Rover or Rover/Combo application is selected.
Dash 2000 Patient Monitor
2005873-001
MANUAL
ALARM
PRINT
GRAPH
GRAPH:
WINDOW
LOCATION:
LOCATION:
LOCATION:
ICU1
ICU1
ICU1
CS1
CS1
CS1
WRITER
LASER
WRITER
058
Revision C
