Numeric Popup

Subordinate Menus

1-22
ECG LIMITS
RETURN
>
HR
MAIN
MENU
The available selections are many; therefore, only the current selection is
displayed. The arrows are highlighted indicating the Trim Knob control can
be rotated. Rotating the Trim Knob control will change the displayed value
in the popup menu. Like the Pointer Popup, the change will not be in effect
until the Trim Knob control is pressed.
Whenever possible, short popup menus are displayed when selecting menu
options. In some cases, however, a whole new menu is displayed. This is a
menu within a menu, or a subordinate menu.
Many, but not all, subordinate menus have the PREV MENU option to
allow you to return to the previously displayed menu.
Following is an example of a subordinate menu:
Display the ECG Menu.
MAIN
MENU
From the ECG Menu select ANALYSIS SETTINGS—the entire ECG
Menu is replaced with the subordinate ANALYSIS SETTINGS Menu.
MAIN
MENU
PREV
MENU
ANALYSIS SETTINGS Menu
Select PREV MENU to redisplay the ECG Menu.
Dash 2000 Patient Monitor
2005873-001
