Defib Sync/Analog Output

ECG Acquisition
Modules
14-2
The configuration for the analog output from the ECG acquisition modules
is detailed below. Analog output is obtained through the Defib Sync
connector on the rear of the monitor.
ECG ANALOG OUTPUT:
Top displayed lead including augmented leads. If pace is on there is an
enhanced pacer pulse (5 volts at 2 milliseconds) when pacemaker triggering
is detected.
In the event of a LEAD FAIL, refer to the following:
Lead Failed AHA Label
Right arm RL
LA
Left arm
Left leg LL
Chest V
Right leg RL
*A right leg lead fail causes an all LEADS FAIL on the screen and a buzz is
output.
NOTES:
1. All ECG outputs are 1 volt per millivolt referred to input.
2. In single lead mode, if the specified lead is not available, a buzz will be
output.
DIGITAL SYNCHRONIZATION OUTPUT:
A digital sync output is available with a return marker. For the technical
specifications refer to appendix Technical Specifications, section Analog
Out and Defibrillator Synchronization Pulse.
Dash 2000 Patient Monitor
2005873-001
IEC Label ECG Analog Out
R III
L II
F I
C II
N Buzz*
Revision C
