All Limits

Viewing an All Limits
Screen
Revision C
The ALL LIMITS menu option allows you to view the high and low alarm
limits and unit of measurement for each parameter currently monitored.
You can change the limits for any monitored parameter without having to
go into each individual parameter menu.
1. Select ALL LIMITS option from the Alarm Control Menu.
2. An information window is displayed on the screen and a popup menu is
displayed in the menu area.
21-NOV-2000 16:27
II
SETUP DEFAULT LIMITS
>
RETURN
HR
SPO2
RR
RR-APNEA
NBP-S
NBP-D
NBP-M
TP
MAIN
MENU
PREV.
MENU
ALL LIMITS Popup Menu and Information Window
The information window shows a list of the patient parameters currently
monitored, the units by which they are measured, and the high and low
limits currently in effect.
Dash 2000 Patient Monitor
2005873-001
DAK.BED 1
UNITS LOW HIGH
BPM 50 150
% 90 105
#/MIN 5 55
SEC 20
mmHg 80 200
mmHg 20 120
mmHg 40 140
˚C 30.0 42.0
ALL
LIMITS
046
4-7
