Temperature (Temp); Invasive Blood Pressure (Bp) - GE Medical Systems Dash 2000 Operator's Manual

Temperature (TEMP)

Invasive Blood Pressure (BP)

Revision C
Number of channels:
Input specifications:
Probe type:
Temperature range:
Resolution:
Output specifications:
Parameter displayed:
Linearity:
Accuracy:
Alarms:
Number of channels:
Transducer sites:
Transducer
requirements:
Excitation voltage:
Transducer output:
Input specifications:
Range:
Offset:
Input impedance:
Common mode:
Differential:
Output specifications:
Frequency response:
Gain stability:
Zero balance range:
Zero balance accuracy:
Zero balance drift:
Dash 2000 Patient Monitor
2005873-001
1
YSI Series 400
0 °C to 45 °C (32 °F to 113 °F)
±0.1 °C (±.18 °F)
TP
<1 % from 30 °C to 42 °C
(independent of source) ±0.1 °C (±.18 °F)
User-selectable upper and lower limits
for TP
1 (optional)
Arterial (ART), femoral artery (FEM),
pulmonary artery (PA), central venous
(CVP), right atrial (RA), left atrial (LA),
intracranial (ICP), and special (SP).
In neonatal mode: umbilical artery
catheter (UAC) or umbilical venous
catheter (UVC)
5 V ±0.1 %
dc
50 µV/V/cmHg
-25 mmHg to 300 mmHg
±150 mmHg
>100 k at 50/50 Hz
>100 k from dc to 60 Hz
dc to 50 Hz (+0/-3 dB)
<±0.1%/°C, and <±0.1% over any 24 hour
period
±150 mmHg
±1 mmHg
±1 mmHg over 24 hours
14-27
