Temperature Menu Options

Units

TP Limits

Revision C
This direct action menu option switches the units of measure between Celsius
(C) and Fahrenheit (F).
A new set of menu options is displayed to allow you to adjust these limits.
Follow this procedure:
1. Select TP LIMITS option from the Temperature Menu. An information
window is displayed on the screen and a new set of menu options is
displayed in the menu area.
21-NOV-2000 16:27
II

TP LIMITS

>
RETURN
TP
MAIN
MENU
TP LIMITS Menu and Information Window
2. Rotate the Trim Knob control to move the pointer (>) through the list.
3. Press the Trim Knob control when the pointer is in front of TP. The
parameter label highlights.
4. Turn the Trim Knob control to highlight the low or high limit.
5. Press the Trim Knob control again and rotate to change value. Press
the Trim Knob control to complete the change.
6. Rotate the Trim Knob control to highlight the parameter label and
press to unhighlight.
7. Select RETURN when all changes are completed. The popup men and
information window close.
Dash 2000 Patient Monitor
2005873-001
DAK.BED 1

UNITS

LOW HIGH
C 00.0 42.0
TP
LIMITS
