Alarm Graph; Speed - GE Medical Systems Dash 2000 Operator's Manual

Alarm Graph

Speed

5-20
This menu option allows you to turn automatic alarm graphs off and on.
This is a direct action menu option. Selecting this option switches back and
forth between off and on.
MAIN
MENU
PREV.
MENU
An arrhythmia alarm graph continues to run until a normal sinus rhythm
is again detected, or until you manually stop it at the writer. All other
alarm graphs will run for 20-seconds.
NOTE: To convert an arrhythmia alarm graph to a manual graph, you
must stop the graph using the GRAPH GO / STOP key on the
writer and immediately restart the graph.
The speed at which a graph strip is printed is controlled with this menu
option. The slower the speed, the more condensed the data will be. This
option affects manual graphs only and must be selected before starting the
graph.
NOTE: Alarm graphs always run at 25 millimeters per second.
1. Select the GRAPH TIME/SPEED option from the Graph Setup Menu.
A menu with the two options SPEED and TIMED GRAPH appears.
2. Select the SPEED option. A popup menu opens displaying all choices.
MAIN
MENU
PREV.
MENU
NOTE: A laser printer does not support the 0.1 millimeters per second

speed.

3. Rotate the Trim Knob control so the pointer is in front of the speed you
want.
4. Press the Trim Knob control to confirm the change and close the popup
menu.
Dash 2000 Patient Monitor
2005873-001
WAVEFORM WAVEFORM
ECG 1:
2:
LEAD III
ART
ALARM GRAPH
GRAPH
GRAPH:
LOCATION
ON SPEED
ALARM GRAPH Option
SPEED:
0.1 10
25
0.5 12.5
1 >25
5 50
SPEED Popup Menu
3:
OFF
TIME /
060
061
Revision C
