View Older / View
Newer

Time Interval

Specific Time

Page Down and Page
Up
6-4
Described below are the Vital Signs Menu options.
Each of these direct action menu options will move the data displayed either
backward or forward in time if data is available.
Select TIME INTERVAL to choose the time interval between each of the
displayed columns of data. This does not affect data collection, only how it is
displayed.
MAIN
MENU
PREV.
MENU
TIME INTERVAL Popup Menu
1. Rotate the Trim Knob control to move the pointer in front of the time
interval of choice.
2. Press the Trim Knob control to close the popup menu and effect the
change.
Select SPECIFIC TIME option to open a popup menu which allows you to enter
a specific time you want to find and display in vital signs.
MAIN
MENU
PREV.
MENU
SPECIFIC TIME Popup Menu
1. Rotate the Trim Knob control to move the highlight into the date and time.
(The popup menu opens with the current date and time.)
2. Press the Trim Knob control when an element in the date or time is
highlighted. Rotate to make a change.
3. Press the Trim Knob control to complete the change, and rotate to highlight
the next element in the date and time.
4. Close the popup menu by rotating the Trim Knob control to highlight
SPECIFIC TIME, then press the Trim Knob control. The specific time you
requested (or the time closest to it if your TIME INTERVAL is set for other
than one minute) will appear in the middle column of the information
window.
These direct action menu options work just like VIEW OLDER and VIEW
NEWER but instead of moving the data in time, they display any additional data
not displayed on the screen due to space restrictions.
Dash 2000 Patient Monitor
2005873-001
TIME
1 HR
VIEW
INTERVAL:
30 MINS
OLDER
15 MINS
15 MINS
>
5 MINS
PAGE
1 MIN
DOWN
SPECIFIC
TIME
27 NOV 2000 16:27
075
076
