Timed Graph

Revision C
The duration at which a manual graph is printed is controlled with this
menu option.
1. Select the GRAPH TIME/SPEED option from the Graph Setup Menu.
A menu with the two options SPEED and TIMED GRAPH appears.
2. Select the TIMED GRAPH option. A popup menu opens displaying all
choices.
MAIN
MENU
PREV.
MENU
TIMED GRAPH Popup Menu
3. Rotate the Trim Knob control so the pointer is in front of your choice.
4. Press the Trim Knob control to confirm the change and close the popup
menu.
