Getting to the
Temperature Menu
13-4
To display the Temperature menu use the Trim Knob control to select the TP
parameter label. Remember, selecting with the Trim Knob control is a two-step
process—rotate to highlight, then press to select.
Selecting the TP Parameter Label
The Temperature menu is displayed at the bottom of the screen.
MAIN
MENU
With the Trim Knob control, you now can select any of the displayed options:
•
UNITS—switch the units of measurement between Celsius and
Fahrenheit.
•
TP LIMITS—display a new menu and an information window to adjust
alarm limits for the temperature site.
Dash 2000 Patient Monitor
2005873-001
42.0/
TP
37.8
UNITS: TP
CELSIUS LIMITS
Temperature Menu
30.0
C
136
137
