Optional Laser
Printer
1-6
An optional laser printer (not shown) connects to the central station. It is
identified on the Dash monitor as LASER when choosing a graph location.
(Refer to the Monitor Setup chapter for more details.)
When you choose the laser printer as the print window location, it can print
any printable information window when it is displayed and the GRAPH
GO/STOP key is pressed.
When you choose the laser printer as the manual graph location, it will
print the waveforms as selected in Graph Setup when the GRAPH
GO/STOP key is pressed. It prints 20 seconds of waveforms per page in a
cascade format when the graph speed is set for 25 millimeters per second.
There will be a delay of approximately one minute until the first page is
printed, then it will run until all patient data is printed.
NOTE: The one-minute delay does not mean the data printed is delayed. It just
takes that long for the information to be processed by the laser printer.
The amount of data printed will increase and the delay will be longer if
a speed slower than 25 mm/s is chosen.
When you choose the laser printer as the alarm graph location, it will
provide 20 seconds of waveforms per page in a cascade format, but again,
there will be a delay of one minute until the first page is printed.
