QRS Width

Changing QRS Width

8-22
With the QRS WIDTH option you can choose between normal and narrow
QRS widths.
•
QRS normal—Use the Normal mode for ECG rhythms that have QRS
complex widths of approximately 70 ms or wider. This includes almost
all adult patients and also any patient with electronic ventricular
pacing.
•
QRS narrow—The Narrow mode is intended for use with all neonatals
and pediatric patients who have a QRS complex width of 120 ms or less.
NOTE: Full range of QRS amplitude sensitivity is achieved for QRS
<80 ms.
The QRS WIDTH option opens a popup menu that allows you to specify the
QRS width type to NORMAL or NARROW. The selected width type will be
sent to the monitor for use in the ECG analysis algorithms.
To change the QRS width, follow this procedure:
1. Select QRS WIDTH from the Analysis Settings menu.
MAIN
MENU
PREV.
MENU
2. Rotate the Trim Knob control to place the pointer in front of your
The change will not take effect until the Trim Knob control is
choice.
pressed and the popup menu closed.
3. Press the Trim Knob control to confirm the change and close the popup
menu.
Dash 2000 Patient Monitor
2005873-001
> NORMAL
NARROW
QRS
HELP
WIDTH:
NORMAL
QRS WIDTH Popup Menu
DETECT
PACE:
OFF
