Pressure Menu Options

Scales

Revision C
In most cases, the CVP menu is used in this section to demonstrate the

pressure menu options.

The SCALES option allows you to change the scale on which the pressure
waveform is displayed on the screen. Changing the scale changes the size of
the waveform. Scales can be set in Monitor Defaults.
Follow this procedure:
1. Select CVP SCALES option from the CVP Menu. A popup menu opens
showing the scale sizes available. The scale currently used is
designated with the pointer (>).
MAIN
MENU
CVP SCALES Popup Menu
NOTE: The auto scale is only an option once the pressure is
zeroed.
2. With the Trim Knob control, move the pointer to the desired scale size.
The scale on the display will not change until the Trim Knob control is
pressed. Pressing the Trim Knob control also closes the popup menu.
Selecting AUTO will calculate a scale based on the patient's current
blood pressure.
NOTE: Auto scaled waveforms will graph on a slightly different
scale than displayed.
Dash 2000 Patient Monitor
2005873-001
CVP
AUTO 100

SCALES:

300 60
160
200 40
160 30
>
099
9-7
