Software Features

Menus

Menu Timeout

Main Menu

Revision C
A menu, like the name implies, is a selection of available options. These
options are displayed at the bottom of the screen and are accessed with the
Trim Knob control. Some menus may have some empty spaces. These
spaces are available for future software enhancements.
There are two important menu options to note.
is found in every menu with the exception of the Main Menu.
MAIN MENU
This option will always take you back to the Main Menu. Use it
when you are finished making adjustments or accessing stored
information.
PREV MENU
This option allows you to back up to the previous menu when a
subordinate menu is displayed.
Think of these as escape or exit options.
The monitor automatically returns to the Main Menu (refer to the figure
below) when you have displayed another menu and have not used the Trim
Knob for 5 minutes (default time). This is a Monitor Defaults setting
(SETUP DEFAULT DISPLAY) which can be set for a longer period of time
or no timeout at all. Some menus, such as Vital Signs and trends, are not
affected by the timeout setting. You must exit them using one of the exit
options described above.
The Main Menu has one menu option, MORE MENUS, in the lower left
corner of the screen. With the Main Menu displayed, the screen shows all
monitored parameters and waveforms.
21-NOV-1998 16:27
II
SPO
2
160
ART
0
MORE

MENUS

+ -
From the Main Menu, you access a parameter menu by selecting the
appropriate parameter label, or you can access other menus (not related to
a specific parameter) by selecting the MORE MENUS option.
Dash 2000 Patient Monitor
2005873-001
One or both of these options
DAK.BED 1 150/
ECG
60
105/
SPO
2
98
* * *
51
RT
200/
NBP
S
X/
ADT
42.0/ 30.0 200/
TP ART
C S
117/
36.6
59
RT
The Main Menu
50
90
80
mmHg
X
X
80
mmHg
46
73
010
1-19
