10-4
NOTE: Due to the difference in these methods, one cannot be used to
check the accuracy of the other.
BP
Dash 2000 Monitor—NBP Connector
NOTE: The NBP cable connector is insulated and it is defibrillator-proof
(
). Use only the BP cuffs listed in the enclosed publication
"Accessories – Dash 2000/3000". These cuffs ensure patient safety
and protect the device during defibrillation and electrosurgery.
Dash 2000 Patient Monitor
2005873-001
SPO 2
ECG
Temp
NBP Cable Connector
NBP
107
Revision C
