RDL-3000 FAMILY
Important Security Guidelines:
1. Store encryption keys and certificate information in a secure location.
2. Always use secure transfer (e.g., SSH or SSL) when working with encryption keys
and certificates.
3. It is recommended to use the RDL-3000 local Ethernet port to transfer encryption
keys and certificates, or sftp if loading certificates or keys across an open network.

6.2 Wireless Authentication

Wireless authentication is a standard feature on all RDL-3000 systems.

Out-of-Box Operation

Wireless authentication is not supported out of box. Each RDL-3000 system to use
wireless authentication must meet the following requirements:
1. The operator must generate and load X.509 certificate and key files
2. The wireless certificate and key files must be loaded into the user (usr) table. The
files can only be loaded using the CLI interface (Telnet or SSH). Reboot the RDL-
3000 to activate the certificate and key.
3. Configure and activate authentication services.

Generate X.509 Certificate and Key Files

Use a commercially available tool to create the required X.509 certificates and keys. The
filenames used must comply with the following requirements:
usr_wacert_<mac>.der X.509 Certificate Authority: The root CA X.509 certificate for the
usr_wcert_<mac>.der
usr_wkey_<mac>.der

Load Wireless X.509 Certificates and Keys

Use the following steps to setup wireless authentication:
1. Copy the certificate and key files to the default directory of a TFTP server.
2. Use the CLI command 'load' to copy the certificate and key files from the TFTP
server to the RDL-3000.
3. Use the CLI command 'show files usr' to verify the files have been successfully
loaded.
4. Reboot the RDL-3000 to activate changes.

Enabling Authentication

The wireless X.509 certificate and key files must be loaded into the usr table and the
RDL-3000 rebooted to activate the new keys before wireless authentication can be
enabled. Use one of the following methods to enable authentication:
CLI:
Web:
Note: Save the configuration to activate changes.
70-00158-01-08
USER MANUAL
product. The same certificate is used for all units.
X.509 Certificate: The unit X.509 certificate that has been signed by
the CA. This certificate includes the unit's public key.
Private Key: This certificate includes the unit's private key. The
private key must be kept secret and not shared with anyone. The
data used to create the keys should also be stored in a secure area.
set x509auth on
Configuration screen -> Wireless Security Configuration:
X.509 Authentication Enable
Proprietary Redline Communications © 2011 Page 136 of 150 December 7, 2011
