Setting Up The Measurement - Larson Davis SoundAdvisor 831C Reference Manual

FIGURE 15-1 Setup File Save As
FIGURE 15-2 Name File
Specify Run Mode
Review
TRY THIS
"Measurement Setup" on
page 6-1 and indicate all the
parameters for each setup
page that need for your
measurement.
FIGURE 15-3 Continuous Mode
SoundAdvisor Model 831C
Step 2 Name file a unique name. This example will use
"mHistoryEx" as the setup file name. Save.
Step 3 With your setup highlighted, use the top right softkey to
navigate to Control. Choose a run mode:
Continuous and Timer Modes
For these run modes, when the Measurement History is enabled, a
series of measurements will be performed automatically, each running
for a user-defined time interval, until the file is stored.

Setting up the Measurement

15-2
