18.8 Sound Recording Playback

G4 LD Utility on a
TAKE NOTE
PC will playback all audio files
recorded or saved.

18.8.1 USB Headphone/Speaker

18.8.2 Playback from Session Log

FIGURE 18-14 Session Log Playback

18.9 Storing Sound Recordings

FIGURE 18-15 Saved Data File
SoundAdvisor Model 831C
Sound recordings are saved as .wav (uncompressed) and .ogg
(compressed) files and can be played back on the SoundAdvisor if a
USB compatible device is inserted, or on a PC using G4 LD Utility.
The SoundAdvisor supports a USB Audio headphone or headset for
audio playback.
You can play back a sound recording from the Session Log tab on the
SoundAdvisor, as long as a playback device is inserted.
Playback can continue until you've saved your data file. You can
download your data file using G4 LD Utility to listen to the saved data
files. Alternatively, you can hear saved sound recordings in the Data
File Manager.
After your data file has been downloaded, you can find your sound
recordings on the Session Log, Measurement History, and Event History

Sound Recording Playback

18-10
