Power Page - Larson Davis SoundAdvisor 831C Reference Manual

4.3.7 Power Page

FIGURE 4-8 Power Page on the Live Tab
The current date and
time can easily be seen
on this page.
Voltage of the battery
and the USB external
power source can be
tracked here.
Table 4.1 Run Timer Behavior
Measurement Mode
Manual Run/Stop
Timed Stop
Stop When Stable
Continuous
with Measurement History Counts down the end of the interval. If interval
with Daily Auto-Store
SoundAdvisor Model 831C
The power page on the Live tab shows time and date, power
information, memory, and battery information.
Run Timer
The run timer is the time the current measurement has been running,
in Manual Start/Stop mode. Depending on your run mode the Run
Timer will function differently.
The current measurement run time.
The timer will be set to the Timed Stop time and
will count down until the end of the
measurement.
The current measurement run time.
The current measurement run time.
time sync is selected the first interval may be
truncated to sync with the system clock.
Counts down to the auto-store. Take note that
the run timer will be counting even when the
measurement is stopped, since it is counting
down to the daily auto-store time.
Live Displays
Checking the internal
temperature of the
meter periodically is
always good safety
practice.
The internal
memory
information is
also available
on the Power
page.
Run Timer
4-6
