Sleep Icon
To learn more
LEARN MORE
about power saving options,
see "Power" on page 9-3.
File Operation Icon
File Operation Icon
FIGURE 2-18

2.5.4 Display Menus

SoundAdvisor Model 831C
When the SoundAdvisor is not connected to a PC, it can be put in a
power saving mode that shuts down the analog circuitry, including the
preamplifier, to save battery power. The power save icon will be
displayed in the location where the measurement status icons appear.
FIGURE 2-17 Sleep Icon
The file operation icon will appear on the status bar to indicate that a
file is currently being saved onto the USB, moved from the USB to
meter, or is being copied. All these operations are done in the Data File
Manager, see "Measurement Data Files" on page 8-1.. It is a standby
icon that will disappear once the operation in complete.
The SoundAdvisor features and functions are organized into three
general menus:
Main Menu
Accessed using the center softkey that indicates Menu
• Setup Manager
• Mark Sound Type
Any Level Menu - Access on profile display by pressing 5
•
• Adjust Graph
• Print Screens (only available with printer inserted)
Tools Menu
Accessed using 3 Tools or the menu icon on the display
• Data File Manager
• Calibrate
• Setup Manager
• System Properties
• About
• Lock
• System Utilities
• Communication
Displays and Icons 2-13
