Module15

15.1 Overview ............................................................................................................................15-1

15.2 Enabling Measurement History ........................................................................................15-1

15.3 Setting up the Measurement ............................................................................................15-1
15.3.1 Create Measurement History Setup File ............................................................15-1
15.4 Making a Measurement .....................................................................................................15-4
15.5 Viewing Measurement Data ..............................................................................................15-4
15.5.1 Current Data Display ...........................................................................................15-4
15.5.2 Measurement History Data Display ...................................................................15-5
15.5.3 Data File ...............................................................................................................15-6
15.6 Storing Measurement History ...........................................................................................15-6
15.1 Overview
Firmware options
TAKE NOTE
831C-ELA or 831C-MSR (MSR
does not include events) must
be purchased and enabled in
order to use this option.
15.2 Enabling Measurement History
15.3 Setting up the Measurement
15.3.1 Create Measurement History Setup File
Name the Setup
SoundAdvisor Model 831C
Measurement History
T
he following module provides the procedures using the
Measurement History option on the SoundAdvisor. Measurement
History is a sequence of measurements contained in one file, as defined
in a setup file.
To ensure that the Measurement History option is successfully
enabled and visible, see "Enabling/Disabling Optional Firmware" on
page 14-4.
While measurement parameters can be indicated directly in the Active
setup, it is good practice to first create a user-defined setup file for any
specific measurement you perform. Once created, you can make that
setup active. The following section will discuss how to do this.
To create a new setup file, follow these steps
Step 1 Navigate to Tools or Menu  Setup Manager. Arrow down
to Default and press ENTER. A Menu will appear. Select
Save As.
Overview 15-1
