8.3 Data File Manager

FIGURE 8-3

Data File Manager

A USB drive is inserted,
so the USB icon is
displayed.
This is the available
storage, unless the USB
is connected and set
for store-only, then it
will be the USB storage
space.
The data file name is
the name indicated in
the setup and used for
that measurement.
FIGURE 8-4 Data File Manager Menu
Highlight a data
file before
selecting Menu.
The options in
the menu will
affect the
highlighted
data file.
SoundAdvisor Model 831C
Data File Manager is a directory of all saved measurement data files.
Data File Manager
The current measurement
can be running, paused, or
stopped while viewing
data files.
The top file is saved on the
USB drive, and the one
below is saved on the
meter's internal memory in
this example.
You can Rename,
Delete, and Delete All
Internal Files.
Refresh List and
navigation commands
are on the menu as
8-3
