Make Setup Active

15.4 Making a Measurement

15.5 Viewing Measurement Data

15.5.1 Current Data Display

SoundAdvisor Model 831C
Manual and Stop When Stable Mode
For these run modes, when Measurement History is enabled, at the
conclusion of a measurement, the data must be manually saved.
Checking the "Enable Measurement History" check box does not add
additional parameter fields to the display as it does with Continuous,
Single Block Timer and Daily Timer modes.
With Measurement History enabled, sequentially pressing the 7 and
9 keys will store the measurement and initiate another
measurement, eliminating the need to perform a separate data store
operation.
Step 4 After indicating a mode and settings, Save.
Step 5 In the Setup Manager, select the MHistoryEx setup and
select Set To Active.
To begin your measurement, press 9 (RUN/PAUSE) on the meter. For
a basic measurement run overview, see "Making a Measurement" on
page 7-1.
When the first measurement is in progress, the data will display on the
Current tab. When that measurement is complete, its data will display
on the Measurement tab. The Current tab is then reset and begins
displaying data for the next measurement in progress. At any time the
Current tab displays the measurement currently in progress.
Current can display data pages just like Live or Overall, depending on
the firmware options enabled and the setup used. Press the 8 and
2 keys to navigate through these different pages. For more
information on these pages, see "Data Display" on page 4-1.

Making a Measurement

15-4
