Siemens LMS14 User Manual page 457

None ¦ DHW sensor B31 ¦ Collector sensor B6 ¦ DHW circulation sensor B39 ¦ Buffer sensor B4 ¦ Buffer sensor B41 ¦ Flue gas
temp sensor B8 ¦ Common flow sensor B10 ¦ Solid fuel boiler sensor B22 ¦ DHW charging sensor B36 ¦ Buffer sensor B42 ¦
Common return sensor B73 ¦ Cascade return sensor B70 ¦ Swimming pool sensor B13 ¦ Solar flow sensor B63 ¦ Solar return
sensor B64 ¦ Primary exch sensor B26
5950 Function of input H1
None ¦ Optg mode change HCs+DHW ¦ Optg mode changeover DHW ¦ Optg mode changeover HCs ¦ Optg mode changeover
HC1 ¦ Optg mode changeover HC2 ¦ Optg mode changeover HC3 ¦ Heat generation lock ¦ Error/alarm message ¦ Consumer
request VK1 ¦ Consumer request VK2 ¦ Release swi pool source heat ¦ Excess heat discharge ¦ Release swi pool solar ¦
Operating level DHW ¦ Operating level HC1 ¦ Operating level HC2 ¦ Operating level HC3 ¦ Room thermostat HC1 ¦ Room
thermostat HC2 ¦ Room thermostat HC3 ¦ DHW flow switch ¦ DHW thermostat ¦ Pulse count ¦ Checkb sign flue gas damper ¦ Start
prevention ¦ Boiler flow switch ¦ Boiler pressure switch ¦ Consumer request VK1 10V ¦ Consumer request VK2 10V ¦ Pressure
measurement 10V ¦ Output request 10V
5951 Contact type H1
NC ¦ NO
5953 Voltage value 1 H1
5954 Function value 1 H1
5955 Voltage value 2 H1
5956 Function value 2 H1
5960 Function input H3
None ¦ Optg mode change HCs+DHW ¦ Optg mode changeover DHW ¦ Optg mode changeover HCs ¦ Optg mode changeover
HC1 ¦ Optg mode changeover HC2 ¦ Optg mode changeover HC3 ¦ Heat generation lock ¦ Error/alarm message ¦ Consumer
request VK1 ¦ Consumer request VK2 ¦ Release swi pool source heat ¦ Excess heat discharge ¦ Release swi pool solar ¦
Operating level DHW ¦ Operating level HC1 ¦ Operating level HC2 ¦ Operating level HC3 ¦ Room thermostat HC1 ¦ Room
thermostat HC2 ¦ Room thermostat HC3 ¦ DHW flow switch ¦ DHW thermostat ¦ Pulse count ¦ Checkb sign flue gas damper ¦ Start
prevention ¦ Boiler flow switch ¦ Boiler pressure switch ¦ Consumer request VK1 10V ¦ Consumer request VK2 10V ¦ Pressure
measurement 10V ¦ Output request 10V
5961 Contact type H3
NC ¦ NO
5963 Voltage value 1 H3
5964 Function value 1 H3
5965 Voltage value 2 H3
5966 Function value 2 H3
5970 Function input H4
None ¦ Optg mode change HCs+DHW ¦ Optg mode changeover DHW ¦ Optg mode changeover HCs ¦ Optg mode changeover
HC1 ¦ Optg mode changeover HC2 ¦ Optg mode changeover HC3 ¦ Heat generation lock ¦ Error/alarm message ¦ Consumer
request VK1 ¦ Consumer request VK2 ¦ Release swi pool source heat ¦ Excess heat discharge ¦ Release swi pool solar ¦
Operating level DHW ¦ Operating level HC1 ¦ Operating level HC2 ¦ Operating level HC3 ¦ Room thermostat HC1 ¦ Room
thermostat HC2 ¦ Room thermostat HC3 ¦ DHW flow switch ¦ DHW thermostat ¦ Pulse count ¦ Checkb sign flue gas damper ¦ Start
prevention ¦ Boiler flow switch ¦ Boiler pressure switch ¦ Flow measurement Hz
5971 Contact type H4
NC ¦ NO
5973 Frequency value 1 H4
5974 Function value 1 H4
5975 Frequency value 2 H4
5976 Function value 2 H4
5977 Function input H5
None ¦ Optg mode change HCs+DHW ¦ Optg mode changeover DHW ¦ Optg mode changeover HCs ¦ Optg mode changeover
HC1 ¦ Optg mode changeover HC2 ¦ Optg mode changeover HC3 ¦ Heat generation lock ¦ Error/alarm message ¦ Consumer
request VK1 ¦ Consumer request VK2 ¦ Release swi pool source heat ¦ Excess heat discharge ¦ Release swi pool solar ¦
Operating level DHW ¦ Operating level HC1 ¦ Operating level HC2 ¦ Operating level HC3 ¦ Room thermostat HC1 ¦ Room
thermostat HC2 ¦ Room thermostat HC3 ¦ DHW flow switch ¦ DHW thermostat ¦ Pulse count ¦ Checkb sign flue gas damper ¦ Start
prevention ¦ Boiler flow switch ¦ Boiler pressure switch
5978 Contact type H5
NC ¦ NO
Building Technologies Division User Manual LMS14...
6 The settings in detail
457/617
CC1U7471en
