Entering or Editing Programs

00002
1,2,3...
172
4. Press the Up and Down Arrow Keys to scroll through the program.
This operation is used enter or edit programs. It is possible in PROGRAM
mode only.
RUN
No No
The same procedure is used to either input a program for the first time or to
change a program that already exists. In either case, the current contents of
Program Memory is overwritten.
The program shown in the following diagram will be entered to demonstrate
this operation.
TIM 000
#0123
MOV(021)
#0100
LR 10
ADB(050)
#0100
#FFF6
DM 0000
1. Press the CLR Key to bring up the initial display.
2. Specify the address where the program will begin.
3. Input the address where the program will begin and press the Down Arrow
Key. It is not necessary to input leading zeroes.
A
C A
0
2 0
4. Input the first instruction and operand.
LD
5. Press the WRITE Key to write the instruction to Program Memory. The next
program address will be displayed.
WRITE
If a mistake was made inputting the instruction, press the Up Arrow Key to
return to the previous program address and input the instruction again. The
mistaken instruction will be overwritten
00201READ
AND
↓
00200READ
LD
↑
MONITOR PROGRAM
OK
Address Instruction
00200 LD
12.3 s
00201 TIM
00202 MOV(021)
00203 ADB(050)
00200READ
NOP (000)
↓
00200
C LD
2
00201READ
NOP (000)
