Installing the CPM2C-S
!Caution Be sure that the DIN Track is installed horizontally. Installing the Track verti-
Installation
Lower the CPM2C-S so that the notch on the back of the PC catches the top
of the DIN Track. Push the PC forward until the lock snaps into place.
1) Pull down.
cally will inhibit the airflow that cools the CPM2C-S and could cause overheat-
ing.
Removal
Pry the lock down with a flat-blade screwdriver and pivot the PC upward to
remove it.
Screwdriver
2) Insert
onto track.
3) Push in on
the Unit.
Section 3-3
4) Lock
59
