Changing Timer, Counter Sv - Omron CPM2C-S100C Operation Manual

Programming Console Operations

8-2-21 Changing Timer, Counter SV

Inputting a New SV
Constant
1,2,3...
(Input the new value and press the WRITE Key to write the changes in
memory if no more changes will be made.)
4. Input the new value for the middle word on the display and press the CHG
Key if the rightmost word will be changed. Input the new value and press
the WRITE Key to write the changes in memory if the rightmost word will
not be changed. (In this case, it will not.)
C D
2 3
Note If the CLR Key is pressed before the WRITE Key, the operation will be can-
celled and the 3-word monitor display will return without any changes in data
memory.
There are two operations that can be used to change the SV of a timer or
counter. They are possible in MONITOR or PROGRAM mode only. In MONI-
TOR mode, the SV can be changed while the program is being executed.
RUN
No
The timer or counter SV can be changed either by inputting a new value or by
incrementing or decrementing the current SV.
This operation can be used to input a new SV constant, as well as to change
an SV from a constant to a word address designation and vice versa. The fol-
lowing examples show how to input a new SV constant and how to change the
SV from a constant to an address.
1. Press the CLR Key to bring up the initial display.
2. Display the desired timer or counter.
TIM
3. Press the Down Arrow Key and then the CHG Key.
4. At this point a new SV constant can be input or the SV constant can be
changed to a word address designation
a) To input a new SV constant, input the constant and press the WRITE
Key.
B C
1 2
b) To change to a word address designation, input the word address and
press the WRITE Key.
B
AR
CH
SHIFT
1
HR
*
DM
D0002 3CH CHG?
B
0001 4567 89AB
CHG
1
, , ,
E
!" &')*
WRITE
4
MONITOR
OK OK
00201SRCH
B
TIM
SRCH
1
00201DATA?
T001 #0134 #????
↓
CHG
00201 TIM DATA
E
WRITE
4
00201 TIM DATA
A
0 WRITE
Section 8-2
PROGRAM
001
#0124
HR 10
185
