Specifications

2-1

Specifications

2-1-1

General Specifications

Item
Internal power supply voltage
Communications power supply
voltage
Power con- Internal power
sumption supply
Communica-
tions power sup-
ply
Inrush current
Insulation resistance
Dielectric strength
Noise immunity
Vibration resistance
Shock resistance
Ambient temperature
Humidity
Atmosphere
Power interrupt time
2-1-2

Characteristics

Item
Control method
I/O control method
Programming language
Instruction length
Instructions
Execution time
Program capacity
Maximum I/O capacity
Input bits
Output bits
CompoBus/S input bits
CompoBus/S output bits
Work bits
34
CPM2C-S100C-DRT
CPM2C-S110C-DRT
20.4 to 26.4 VDC (24 VDC −15% to 10%)
11 to 25 VDC (supplied by communica-
tions connector)
4 W max. (See note.)
30 mA max.
25 A max.
20 MΩ min. (at 500 VDC) between insulated circuits
2,300 VAC for 1 min (between insulated circuits)
Conforms to IEC61000-4-4; 2 kV (power lines)
10 to 57 Hz, 0.075-mm double amplitude, 57 to 150 Hz, acceleration: 9.8 m/s
Y, and Z directions for 80 minutes each (Time coefficient; 8 minutes × coefficient fac-
tor 10 = total time 80 minutes)
2
147 m/s three times each in X, Y, and Z directions
Operating: 0 to 55°C
Storage: –20 to 75°C (except for the battery)
10% to 90% (with no condensation)
Must be free from corrosive gas
2 ms min.
Note The above figure for power consumption includes the power consumption of
the Programming Console and Adapter Unit (CIF@@).
Stored program method
Cyclic scan with direct output (Immediate refreshing can be performed with IORF(97).)
Ladder diagram
1 step per instruction, 1 to 5 words per instruction
Basic instructions: 14
Special instructions: 105 instructions, 185 variations
0.64 µs (LD instruction)
Basic instructions:
Special instructions: 7.8 µs (MOV instruction)
4,096 words
362 points
CPU Unit only: 10 points
Expanded system: + 96 points (three 32-point Expansion I/O Units)
CompoBus/S: + 256 points
160 bits: IR 00000 to IR 00915 (Bits not used for input bits can be used for work bits.)
160 bits: IR 01000 to IR 01915 (Bits not used for output bits can be used for work bits.)
128 bits: IR 02000 to IR 02715 (Bits not used for CompoBus/S input bits can be used for work
bits.)
128 bits: IR 03000 to IR 03715 (Bits not used for CompoBus/S output bits can be used for
work bits.)
672 bits: IR 02800 to IR 02915, IR 03800 to IR 04915, and IR 20000 to IR 22715
Specifications
CPM2C-S100C
CPM2C-S110C
---
3 W max. (See note.)
---
Specifications
Section 2-1
2
in X,
