Omron CPM2C-S100C Operation Manual page 171

Cycle Time
Code Mnemonic ON execution
time (µs)
65 PULS 38.4
46.6
40.0
48.1
66 SCL 37.9
39.2
59.9
67 BCNT 24.9
4.32 ms
68 BCMP 35.3
38.3
58.1
69 STIM 25.7
47.8
25.9
47.8
34.0
46.4
10.6
70 XFER 21.3
23.8
1.52 ms
71 BSET 13.8
14.3
971.1
73 XCHG 14.5
29.3
74 SLD 12.3
23.9
2.83 ms
75 SRD 12.3
23.9
2.83 ms
76 MLPX 16.8
46.1
77 DMPX 19.7
52.1
78 SDEC 19.8
48.3
80 DIST 18.7
20.2
43.1
31.0
32.7
55.9
Conditions (Top: min.; bottom: max.)
Specifying a relative pulse for the set pulse out-
put via a word
Specifying a relative pulse for the set pulse out-
put via *DM
Specifying an absolute pulse for the set pulse
output via a word
Specifying an absolute pulse for the set pulse
output via *DM
Specifying a parameter word; constant to word
Specifying a parameter word; word to word
Specifying a parameter *DM ; *DM to *DM
When counting 1 word
When counting 2,048 words via *DM
Comparing constant, results to word
Comparing word, results to word
Comparing *DM, results to *DM
Constant-set one-shot interrupt start
*DM-set one-shot interrupt start
Constant-set scheduled interrupt start
*DM-set scheduled interrupt start
Constant-set timer read
*DM-set timer read
Stopping timer
When transferring a constant to a word
When transferring a word to a word
When transferring 2,048 words using *DM
When setting a constant to a word
When setting a word to a word
When setting *DM to 2,048 words
Word → word
*DM → *DM
Shifting 1 word
Shifting 10 words
Shifting 2,048 words using *DM
Shifting 1 word
Shifting 10 words
Shifting 2,048 words using *DM
When decoding word to word
When decoding *DM to *DM
When encoding word to word
When encoding *DM to *DM
When decoding word to word
When decoding *DM to *DM
When setting a constant to a word + a word
When setting a word to a word + a word
When setting *DM to *DM +*DM
When setting a constant to a stack
When setting a word to a stack
When setting *DM to a stack via *DM
Section 7-1
OFF execution time (µs)
2.6
2.6
2.6
2.6
2.6
2.6
2.6
2.6
2.6
2.6
2.6
2.6
2.6
2.6
149
