Wiring and Connections
3-4-5

Using Terminal Blocks

3-4-6

Connecting I/O Devices

3. Assemble the socket and connector as shown in the following diagram.
Socket
We recommend using the following Terminal Blocks to wire devices to the
CPM2C-S' I/O connector. Refer to 3-4-6 Connecting I/O Devices for details on
I/O wiring.
I/O
Note The allowable current for the XW2Z-@@@A is 1 A. Do not allow the current on
the common terminal to exceed 1 A.
Wire inputs and outputs to the CPM2C-S' CPU Unit as shown in the following
diagrams.
Connector cover
Small screws (3)
Nuts (3)
XW2Z-
Terminal Blocks
XW2B-20G4 (M3 screws)
XW2B-20G5 (M3.5 screws)
XW2D-20G6 (Thin version)
Section 3-4
Small screws (2)
Cable clamp
Connector screws
Nuts (2)
(((
A Cable
67
