Using a Programming Console
CQM1H-PRO01-E,
CQM1-PRO01-E
Attached Cable (2 m)
C200H-PRO27-E
162
The CQM1H-PRO01-E can be connected directly to the CPM2C-S.
Attached Cable (2 m)
Cassette recorded jack
(Cannot be used with the CPM2C-S).
The following Connecting Cables can be used with the C200H-PRO27-E.
Model Cable length
C200H-CN222 2 m
C200H-CN422 4 m
CS1W-CN224 2 m
CS1W-CN624 6 m
LCD display
Mode switch
Operation keys
LCD display
Mode switch
Operation keys
Connection
Connects to the peripheral port on a CPM2C-
CN111 or CS1W-CN114.
Connects directly to the CPM2C-S CPU Unit's
communications port.
Section 8-1
