Omron CPM2C-S100C Operation Manual page 119

AR Area
Word(s) Bit(s)
AR 11 00 to 07 High-speed Counter Range Comparison Flags
00 ON: Counter PV is within comparison range 1
(Note 1)
01 ON: Counter PV is within comparison range 2
02 ON: Counter PV is within comparison range 3
03 ON: Counter PV is within comparison range 4
04 ON: Counter PV is within comparison range 5
05 ON: Counter PV is within comparison range 6
06 ON: Counter PV is within comparison range 7
07 ON: Counter PV is within comparison range 8
08 High-speed Counter Comparison Operation
ON:
OFF:
09 High-speed Counter PV Overflow/Underflow Flag
ON:
OFF:
10 Not used.
11 Pulse Output 0 Output Status
ON:
OFF:
12 Pulse Output 0 Overflow/Underflow Flag
ON:
OFF:
13 Pulse Output 0 Pulse Quantity Set Flag
ON:
OFF:
14 Pulse Output 0 Pulse Output Completed Flag
ON:
OFF:
15 Pulse Output 0 Output Status
ON:
OFF:
AR 12 00 to 11 Not used.
(Note 1)
12 Pulse Output 1 Overflow/Underflow Flag
ON:
OFF:
13 Pulse Output 1 Pulse Quantity Set Flag
ON:
OFF:
14 Pulse Output 1 Pulse Output Completed Flag
ON:
OFF:
15 Pulse Output 1 Output Status
ON:
OFF:
Operating
Stopped
An overflow or underflow occurred.
Normal operation
Pulse output 0 is accelerating or decelerating.
Pulse output 0 is operating at a constant rate.
An overflow or underflow occurred.
Normal operation
Pulse quantity has been set.
Pulse quantity has not been set.
Completed
Not completed
Pulses being output.
Stopped.
An overflow or underflow occurred.
Normal operation
Pulse quantity has been set.
Pulse quantity has not been set.
Completed
Not completed
Pulses being output.
Stopped.
Function
Section 4-5
97
