Omron CPM2C-S100C Operation Manual page 126

PC Setup
Word(s) Bit(s)
Peripheral Port Communications Settings
The following settings are read regularly by the CPU while the PC is ON.
If pin 3 of the CPM2C-S CPU Unit's DIP switch is ON, communications through the CPM2C-S' peripheral port are gov-
erned by the default settings (all 0) regardless of the settings in DM 6650 through DM 6651.
When connecting a computer running OMRON Support Software to the peripheral bus, turn OFF pin 3 of the DIP switch
and set DM 6650 to 0001 (host link port settings specified in DM 6651). The computer cannot be connected to the periph-
eral bus if bits 00 to 03 of DM 6650 are set to 0 (standard port settings).
DM 6650 00 to 03 Port settings
00 (Hex): Standard (1 start bit, 7 data bits, even parity, 2 stop bits, 9,600 bps),
01 (Hex): Settings in DM 6651
(Any other setting specifies standard settings, causes a non-fatal error, and turns ON AR 1302.)
04 to 11 Not used.
12 to 15 Communications mode
0 (Hex): Host Link or peripheral bus; 1 (Hex): No-protocol
(Any other setting specifies Host Link, causes a non-fatal error, and turns ON AR 1302.)
DM 6651 00 to 07 Baud rate
00 (Hex): 1,200 bps; 01 (Hex): 2,400 bps; 02 (Hex): 4,800 bps;
03 (Hex): 9,600 bps; 04 (Hex): 19,200 bps
08 to 15 Frame format
00 (Hex):
01 (Hex):
02 (Hex):
03 (Hex):
04 (Hex):
05 (Hex):
06 (Hex):
07 (Hex):
08 (Hex):
09 (Hex):
10 (Hex):
11 (Hex):
(Any other setting specifies standard settings (1 start bit, 7 data bits; even parity, 2 stop bits,
9,600 bps), causes a non-fatal error, and turns ON AR 1302.)
DM 6652 00 to 15 Transmission delay (0000 to 9999 BCD sets a delay of 0 to 99,990 ms.)
(Any other setting specifies a delay of 0 ms, causes a non-fatal error, and turns ON AR 1302.)
DM 6653 00 to 07 Node number (Host Link)
00 to 31 (BCD)
(Any other setting specifies a node number of 00, causes a non-fatal error, and turns ON
AR 1302.)
08 to 11 Start code selection for no-protocol communications
0 (Hex): Disables start code; 1 (Hex): Enables start code in DM 6649
(Any other setting disables the start code, causes a non-fatal error, and turns ON AR 1302.)
12 to 15 End code selection for no-protocol communications
0 (Hex): Disables end code; 1 (Hex): Enables end code in DM 6649;
2 (Hex): Sets end code of CR, LF.
(Any other setting disables the end code, causes a non-fatal error, and turns ON AR 1302.)
DM 6654 00 to 07 Start code (00 to FF)
(This setting is valid only when bits 8 to 11 of DM 6648 are set to 1.)
08 to 15 When bits 12 to 15 of DM 6648 set to 0:
Sets the number of bytes to receive. (00: 256 bytes; 01 to FF: 1 to 255 bytes)
When bits 12 to 15 of DM 6648 set to 1:
Sets the end code. (00 to FF)
104
Host Link unit number: 0
Start bits Data bits
1 bit 7 bits
1 bit 7 bits
1 bit 7 bits
1 bit 7 bits
1 bit 7 bits
1 bit 7 bits
1 bit 8 bits
1 bit 8 bits
1 bit 8 bits
1 bit 8 bits
1 bit 8 bits
1 bit 8 bits
Function
Stop bits Parity
1 bit Even
1 bit Odd
1 bit None
2 bits Even
2 bits Odd
2 bits None
1 bit Even
1 bit Odd
1 bit None
2 bits Even
2 bits Odd
2 bits None
Section 4-6
