CPM2C-S Features and Functions
Other Functions
Interval Timer Interrupts
Calendar/Clock
Long-term Timer
Expansion Memory Unit
Expansion Memory Unit
EEPROM
Indicator
UPLOAD+DM Button
6
The interval timer can be set between 0.5 and 319,968 ms and can be set to
generate just one interrupt (one-shot mode) or periodic interrupts (scheduled
interrupt mode).
The clock (accuracy within 1 minute/month) can be read from the program to
show the current year, month, day, day of the week, and time. The clock can
be set from a Programming Device (such as a Programming Console) or the
time can be adjusted by rounding up or down to the nearest minute.
TIML(––) is a long-term timer that accommodates set values up to 99,990
seconds (27 hours, 46 minutes, 30 seconds). When combined with the SEC-
ONDS TO HOURS conversion instruction (HMS(––)), the long-term timer pro-
vides an easy way to control equipment scheduling.
The CPM1-EMU01-V1 Expansion Memory Unit is a program loader for small-
size or micro PCs. Using the CPM1-EMU01-V1, simple on-site transfer of
user programs and data memory (DM 6144 to DM 6655) is possible with PCs.
CS1W-CN114
UPLOAD Button
CPM2C-CN111
CPM2C-CIF01-V1
Section 1-1
CPM2C-S
CPM2C-S
