Cycle Time
Code Mnemonic ON execution
time (µs)
50 ADB 14.1
15.6
37.4
51 SBB 14.4
15.9
37.7
52 MLB 16.8
18.5
41.2
53 DVB 16.9
18.6
41.3
54 ADDL 25.3
48.6
55 SUBL 25.3
48.6
56 MULL 79.1
102.1
57 DIVL 73.9
98.6
58 BINL 23.9
38.5
59 BCDL 19.1
33.7
60 CMPL 14.8
30.6
61 INI 68.8
12.0
43.3
51.8
42.8
50.8
60.1
42.7
50.7
17.8
20.0
27.6
146
Conditions (Top: min.; bottom: max.)
Constant + constant → word
Word + word → word
*DM + *DM → *DM
Constant – constant → word
Word – word → word
*DM – *DM → *DM
Constant × constant → word
Word × word → word
*DM × *DM → *DM
Constant ÷ constant → word
Word ÷ word → word
*DM ÷ *DM → *DM
Word + word → word
*DM + *DM → *DM
Word – word → word
*DM – *DM → *DM
Word × word → word
*DM × *DM → *DM
Word ÷ word → word
*DM ÷ *DM → *DM
When converting word data to a word
When converting *DM to *DM
When converting word data to a word
When converting *DM to *DM
Comparing words
Comparing *DM
Starting high-speed counter comparison
Stopping high-speed counter comparison
Specifying a constant when changing high-
speed counter PV
Specifying *DM when changing high-speed
counter PV
Specifying increment mode via constant
Specifying increment mode via *DM
Stopping pulse output
Specifying a constant when changing pulse out-
put PV
Specifying *DM when changing pulse output PV
Stopping synchronized control of high-speed
counter
Specifying a constant when changing interrupt
counter PV
Specifying *DM when changing interrupt
counter PV
Section 7-1
OFF execution time (µs)
2.6
2.6
2.6
2.6
2.6
2.6
2.6
2.6
2.6
2.6
2.6
2.6
