System Configurations

1-2

System Configurations

1-2-1

CPU Units and AC Power Supply Units

CPM2C-S CPU Units
Name
CPU Unit with CompoBus/S Master
Functions
CPU Unit with CompoBus/S Master
and DeviceNet Slave Functions
AC Power Supply Unit (Optional)
Name
AC Power Supply Unit
10
CPM2C-S100C
CPM2C-S110C
Inputs
6 24-VDC inputs
100 to 240 VAC input
24 VDC, 600 mA output
Note General-purpose power supplies such as the S82J-series and S82K-series
Power Supplies can also be used.
Outputs
4 sinking transistor outputs
4 sourcing transistor outputs
4 sinking transistor outputs
4 sourcing transistor outputs
AC Power Supply Unit
Ratings
CPM2C-PA201
Section 1-2
CPM2C-S100C-DRT
CPM2C-S110C-DRT
Model
CPM2C-S100C
CPM2C-S110C
CPM2C-S100C-DRT
CPM2C-S110C-DRT
Model
