I/O Allocation to CompoBus/S Slaves

4-3

I/O Allocation to CompoBus/S Slaves

Note
The CompoBus/S input area (IR 020 to IR 027) and CompoBus/S output area
(IR 030 to IR 037) are allocated for the CompoBus/S Terminal's I/O. The fol-
lowing table shows the I/O allocation of the CompoBus/S Terminal (IN0 to
IN15 and OUT0 to OUT15.)
I/O
IR word
Input area 020
021
022
023
024
025
026
027
Output area 030
031
032
033
034
035
036
037
1. IN0 to IN15 are node numbers of Input Terminals and OUT0 to OUT15 are
node numbers of Output Terminals.
2. When the maximum number of CompoBus/S nodes is set to 16, IN8 to
IN15 and OUT8 to OUT15 can be used as work bits.
3. CompoBus/S Terminals with 8 points or less are allocated I/O bits in byte
units beginning from bit 00 or bit 08.
4. Only even addresses can be specified for 16-point CompoBus/S Termi-
nals.
Bit address
Bit number
15 14 13 12 11 10 9 8
IN1
IN3
IN5
IN7
IN9
IN11
IN13
IN15
OUT1
OUT3
OUT5
OUT7
OUT9
OUT11
OUT13
OUT15
Section 4-3
7 6 5 4 3 2 1 0
IN0
IN2
IN4
IN6
IN8
IN10
IN12
IN14
OUT0
OUT2
OUT4
OUT6
OUT8
OUT10
OUT12
OUT14
