Programming Console Operation Errors

9-2-5

Fatal Errors

Message FALS
No.
Power interruption None
(no message)
MEMORY ERR F1
NO END INST F0
I/O BUS ERR C0
I/O UNIT OVER E1
SYS FAIL FALS** 01 to 99 A FALS(07) instruction has been executed in the program. Check the FALS number to
(** is 01 to 99 or 9F.)
9F
9-3

Programming Console Operation Errors

206
PC operation and program execution will stop and all outputs from the PC will
be turned OFF when any of these errors have occurred. CPM2C-S operation
can't be restarted until the PC is turned OFF and then ON again or a Pro-
gramming Device is used to switch the PC to PROGRAM mode and clear the
fatal error.
All CPU Unit indicators will be OFF for the power interruption error. For all
other fatal operating errors, the POWER and ERR/ALM indicators will be lit.
The RUN indicator will be OFF.
Power has been interrupted for more than 10 ms (2 ms for DC power types.)
Check power supply voltage and power lines. Try to power-up again.
AR 1308 ON: There is a non-existent bit or word address in the user program. Check the
program and correct errors.
AR 1309 ON: An error has occurred in flash memory. Replace the CPU Unit.
AR 1310 ON: A checksum error has occurred in read-only DM (DM 6144 to DM 6599).
Check and correct the settings in the read-only DM area.
AR 1311 ON: A checksum error has occurred in the PC Setup. Initialize the PC Setup
and input the settings again.
AR 1312 ON: A checksum error has occurred in the program. Check the program and
correct any errors detected.
AR 1313 ON: A checksum error has occurred in the expansion instructions data and all
function codes have been set the their default values. Reset the expansion instructions.
AR 1314 ON: Data was not maintained in an area specified for holding. Clear the error,
check the data in the areas specified for holding, and try again.
AR 1315 ON: A CompoBus/S Master ASIC error occurred. Replace the CPM2C-S.
END(01) is not written in the program. Write END(01) at the end of the program.
An error has occurred during data transfer between the CPU Unit and an Expansion I/O
Unit or Expansion Unit. Check the Unit's connecting cable.
Too many Expansion Units or Expansion I/O Units (more than 5) have been connected.
Check the Unit configuration. Do not connect more than 3 Expansion Units or Expansion
I/O Units.
determine the conditions that caused execution, correct the cause, and clear the error.
The cycle time has exceeded the Maximum (Watch) Cycle Time setting (DM 6618).
Check the cycle time and adjust the Maximum Cycle Time setting if necessary.
The following error messages may appear when performing operations on the
Programming Console. Correct the error as indicated and continue operation.
Message
REPL ROM An attempt was made to write to write-protected memory. Set bits 00
to 03 of DM 6602 to "0."
PROG OVER The instruction at the last address in memory is not NOP(00). Erase
all unnecessary instructions after END(01).
ADDR OVER An address was set that is larger than the highest memory address
in Program Memory. Input a smaller address.
SETDATA FALS 00 has been input, and "00" cannot be input. Reinput the data.
ERR
I/O NO. ERR A data area address has been designated that exceeds the limit of
the data area, e.g., an address is too large. Confirm the requirements
for the instruction and re-enter the address.
Note Refer to the relevant Support Software Operation Manual for details on errors
that may appear when operating the SSS or SYSMAC-CPT Support Soft-
ware.
Meaning and appropriate response
Meaning and appropriate response
Section 9-3
