Setting the Mix to the Far End
The master fader (see figure 80 on the previous page) and master fader
6
Mic Program
in the panel create the mix of program and microphone audio that is sent
Mix to Far End
to the far end via the USB output. For best results, adjusting these masters during an
active conference to achieve a proper blend of mic and program material, providing clear,
undistorted audio to the far end.
These settings can be adjusted during a soft codec conference if needed (for example, if
the participants at the far end notice that one audio type is louder than the other). Set this
mix level while the talkers at the near end and far end are speaking at a normal levels for
conferencing, and when program material is being played at the far end.
MediaPort 200 • Standalone Application Setup 92
