Front Panel Lockout (Executive Mode)

To prevent accidental changes to settings, the MediaPort 200 front panel controls can be
locked by placing the unit in lock (executive) mode. While the MediaPort is in lock mode,
Ethernet, RS-232, and USB communication remain available, as well as the ability to exit
lock mode. The front panel lock setting is retained after a power cycle.
•
•
Lock mode also can be enabled and disabled via SIS commands (see
(Executive Mode)

Resetting

Resetting the unit causes various settings to revert to factory defaults. Three methods of
resetting the MediaPort 200 are available:
•
•
•
To enable Executive Mode, press and hold the
simultaneously until
Executive Mode Enabled
(approximately 5 seconds). This same message is displayed any time a front button is
pressed or a knob is rotated.
To disable Executive Mode, press and hold the
Executive Mode Disabled
on page 130).
Reset Button — There are three reset modes (numbered 1, 4, and 5 for the sake
of comparison with Extron IP Link products) that are available by pressing the
button on the rear panel. This button is recessed, so a pointed stylus, ballpoint pen, or
small screwdriver (such as the provided Extron Tweeker) must be used to press it the
appropriate number of times. The
provides an explanation of each reset mode.
Front Panel Menus — To reset the MediaPort to its factory settings but retain the
current firmware version, press the front panel buttons as follows:
1. Press repeatedly until the
Menu
the LCD screen.
2. Press the button until
Next
3. Rotate either knob to display
Adjust
4. Press . The LCD screen displays
Next
5. Press again to start the reset.
Next
While the reset is in process, the screen displays
•
Do not use any front panel buttons or knobs until the reset is done.
When the reset is complete,
•
30 seconds, followed by the default cycle.
SIS Commands — Five types of reset are available via SIS commands (see
page 132):
Erase all user EDID files from flash memory.
•
Reset all device settings to factory defaults except IP and user files (items that are
•
reset are device-dependent).
Perform absolute reset but retain IP settings.
•
Reset all device settings to factory defaults but retain current firmware version.
•
Reset only IP settings to factory defaults.
•
Menu
appears on the LCD screen
Menu
appears in the LCD window (approximately 5 seconds).
Reset Modes Summary
Advanced Configuration
is displayed.
Factory Reset
or
<Yes> <No>
Press Next for Factory Reset
Extron MediaPort 200
MediaPort 200 • Front Panel Operation
and buttons
Next
and buttons until
Next
Front Panel Lock
Reset
table on the next page
menu is displayed on
.
.
Factory Reset Please Wait
is displayed for
Reset
.
on
